Associated Numbers
01182760 01183288 1182495 1182760 130-90125 20437656OE 21314102 220696 243-55207 254630 254630M 45-4280 561.503.123 6035656 CST35656 CST35656AS CST35656ES CST35656GS CST35656OS CST35656RS DRS0321 EAA-151068 LRS02607 M009T62871 M009T62871AM M009T62871ZZ9 M9T62871 M9T62871AM M9T62871ZZ9 MITM9T62871 RAS11432 S-80215 STR71276 UD12422SSpecifications
Kilowatt | 5.5 kW |
Length (L.1) | 326 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
Mount Hole Diameter (C.3) | 11.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BELARUS | 1221.4 | ||
BELARUS | 1523.4 | ||
BELARUS | 2022.4 | ||
BELARUS | 2822 | ||
BELARUS | 3022 | ||
BELARUS | 3522 | ||
DEUTZ | Engine | [TCD] | 01.2012- |
DEUTZ | Engine | [TCD] | 01.2013- |
DEUTZ | Engine | ||
KHD | Engine | ||
VOLVO | L60F | [D6E] | 01.2008- |
VOLVO | L 60 F | ||
VOLVO | L 70 F | ||
VOLVO | L 80 F |
Reference Information
M009T62871 EAA-151068 45-4280 19106N M9TD2071A 1182760 S24MH0021 20900793 M9T62871ZZ9 M9TD2081 22851167 M009TD2071A STR71276 20437656OE LRS2607 561.503.123.390 1182495 UD12422S M9TD2071AM STR5183 M009TD2081AM 254630M ANM12541X 6035656.1 DRS0321 243-55207 M009T62871AM 20437656BN M9TD2071 M009TD2071 21314102 S24MH0021A2 S5221 220696 MITM9T62871 336497 PRSS382 561.503.123.138 CST35656GS 130-90125 CGB-23231 6035656 M009T62871ZZ9 M009TD2081 114873 CST35656AS M9T62871 1183288 561.503.123.130 M009TD2071AM STRS382 RAS11432 561.503.123.370 M9TD2081AM M9T62871AM 254630 LRS02607 88214720 S-80215Video/Publications
01182760 01183288 114873 1182495 130-90125 20437656OE 21314102 220696 243-55207 254630 254630M 45-4280 561.503.123 6035656 CST35656 CST35656AS CST35656ES CST35656GS CST35656OS CST35656RS DRS0321 EAA-151068 LRS02607 LRS2607 M009T62871 M009T62871AM M009T62871ZZ9 M9T62871 M9T62871AM M9T62871ZZ9 MITM9T62871 RAS11432 S-80215 STR71276 STRS382 UD12422SAdd Your Number
