S5214 - Brand new AS-PL Starter motor

Name: Brand new AS-PL Starter motor
Brand: AS-PL
SKU: S5214
Price: 608.17 NZD
Availability: SoldOut

Brand new AS-PL Starter motor

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

MITSUBISHI

Price:

NZ$ 608.17 including GST

NZ$ 528.84 excluding GST

or four payments of $152.04 with
Learn More

UOM:

each

Product Code:

S5214

Quantity In Stock Nationally:

No stock in NZ - Call us for possible procurement options

Availability:

No stock in NZ - Call us for possible procurement options

Information
Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications

M9T66371AM

0001261049 101388V 114872 130-90120 19081015 19081028 19928N 20437136OE 20572417 20714203 21632125 21632127 22602940 255259M 255259P 45-4127 6035631 6035669 811.502.123 811.516.123 8178 88213893 8EA012586-291 CS1472 CST35631 CST35631AS CST35631ES CST35631GS CST35631OS CST35631RS CST35669 CST35669AS CST35669ES CST35669GS CST35669OS CST35669RS EAA-111896 EAA-141334 LRS02455 M009T62171 M009T62171AM M009T62172 M009T62172AM M009T62173 M009T62173AM M009T62174 M009T62174AM M009T66371 M009T66371AM M009T66372 M009T66372AM M009T66373 M009T66373AM M105R3502SE M90R3547SE M90R3558SE M9T62171 M9T62171AM M9T62172 M9T62172AM M9T62173 M9T62173AM M9T62174 M9T62174AM M9T66371 M9T66371AM M9T66372 M9T66372AM M9T66373 M9T66373AM MITM9T66371 MS1-401A STR71227 UD11990S

Kilowatt	5.5 kW
Length (L.1)	318 mm
Mount Hole Center - Center (O.1)	126 mm
Mount Hole Center - Center (O.2)	126 mm
Mount Hole Center - Center (O.3)	126 mm
Mount Hole Diameter (C.1)	13.5 mm
Mount Hole Diameter (C.2)	13.5 mm
Mount Hole Diameter (C.3)	13.5 mm
No./Mount holes	3 qty
No./Mount holes with thread	0 qty
No./Teeth	12 qty
OEM Product	No
Oil Sealed	Yes
Pinion at Rest (B)	48 mm
Product Line	Standard Line
Product Type	Brand new
Rotation	CW
Spigot Diameter (A)	92 mm
Unit Type	MITSUBISHI
Voltage	24 V

Make	Model	Type	Year
RENAULT	440.19 12.8	[DXi13]	03.2009-
RENAULT	460.18 12.8	[DXi13]	05.2006-
RENAULT	460.24 12.8	[DXi13]	05.2006-
RENAULT	460.25 12.8	[DXi13]	05.2006-
RENAULT	460.26 12.8	[DXi13]	05.2006-
RENAULT	460.32 12.8	[DXi13]	05.2006-
RENAULT	480.19 12.8	[DXi13]	03.2009-
RENAULT	480.26 12.8	[DXi13]	03.2009-
RENAULT	500.18 12.8	[DXi13]	05.2006-
RENAULT	500.24 12.8	[DXi13]	05.2006-
RENAULT	500.25 12.8	[DXi13]	05.2006-
RENAULT	500.26 12.8	[DXi13]	05.2006-
RENAULT	500.32 12.8	[DXi13]	05.2006-
RENAULT	520.18 12.8	[DXi13]	08.2009-
RENAULT	520.19 12.8	[DXi13]	08.2009-
RENAULT	520.24 12.8	[DXi13]	08.2009-
RENAULT	520.25 12.8	[DXi13]	08.2009-
RENAULT	520.26 12.8	[DXi13]	08.2009-
VOLVO	420 12.8	[D13C420]	05.2012-
VOLVO	420 12.8	[D13K420]	05.2012-
VOLVO	460 12.8	[D13C460]	05.2012-
VOLVO	500 12.8	[D13C500]	05.2012-
VOLVO	500 12.8	[D13K500]	09.2012-
VOLVO	540 12.8	[D13C540]	05.2012-
VOLVO	540 12.8	[D13K540]	05.2012-
VOLVO	8700 12.1	[DH12D340]	01.1999-
VOLVO	8700 12.1	[DH12D380]	01.1999-
VOLVO	8700 12.1	[DH12E340]	01.1999-
VOLVO	8700 12.1	[DH12E380]	01.1999-
VOLVO	9700 12.1	[DH12D340]	04.2001-
VOLVO	9700 12.1	[DH12D340]	10.2001-
VOLVO	9700 12.1	[DH12D380]	04.2001-
VOLVO	9700 12.1	[DH12D380]	10.2001-
VOLVO	9700 12.1	[DH12D420]	04.2001-
VOLVO	9700 12.1	[DH12D420]	10.2001-
VOLVO	9900 12.1	[DH12D420]	10.2001-
VOLVO	B 12 12.1	[D12C420]	02.2006-
VOLVO	B 12 12.1	[D12D420]	02.2006-
VOLVO	B 12 12.1	[DH12D340]	02.2006-
VOLVO	B 12 12.1	[DH12E340]	02.2006-
VOLVO	B 12 12.1	[DH12E380]	02.2006-
VOLVO	B 12 12.1	[DH12E420]	02.2006-
VOLVO	B 12 12.1	[DH12E460]	02.2006-
VOLVO	FH 12/340 12.1	[D12D340]	01.1995-
VOLVO	FH 12/340 12.1	[D12D340]	08.1993-
VOLVO	FH 12/380 12.1	[D12D380]	01.1995-
VOLVO	FH 12/380 12.1	[D12D380]	08.1993-
VOLVO	FH 12/420 12.1	[D12D340]	08.1993-
VOLVO	FH 12/420 12.1	[D12D420]	01.1995-
VOLVO	FH 12/420 12.1	[D12D420]	08.1993-
VOLVO	FH 12/460 12.1	[D12D460]	08.1998-
VOLVO	FH 12/500 12.1	[D12D500]	09.2001-
VOLVO	FH 16/750 16.1	[D16G750]	05.2012-
VOLVO	FH 16/750 16.1		11.2013-
VOLVO	FH 400 12.8	[D13A400]	09.2005-
VOLVO	FH 400 12.8	[D13B400]	09.2005-
VOLVO	FH 420 12.8	[D13C420]	01.2009-
VOLVO	FH 420 12.8	[D13C420]	05.2012-
VOLVO	FH 420 12.8	[D13K420]	05.2012-
VOLVO	FH 440 12.8	[D13A440]	09.2005-
VOLVO	FH 440 12.8	[D13A440]	09.2006-12.2011
VOLVO	FH 440 12.8	[D13B440]	09.2005-
VOLVO	FH 440 12.8	[D13B440]	09.2006-12.2011
VOLVO	FH 440 12.8	[D13H440]	09.2005-
VOLVO	FH 460 12.8	[D13C460]	01.2009-
VOLVO	FH 460 12.8	[D13C460]	05.2012-
VOLVO	FH 460 12.8	[D13K460]	05.2012-
VOLVO	FH 480 12.8	[D13A480]	09.2005-
VOLVO	FH 480 12.8	[D13A480]	09.2006-12.2011
VOLVO	FH 500 12.8	[D13B500]	01.2009-
VOLVO	FH 500 12.8	[D13B500]	09.2007-
VOLVO	FH 500 12.8	[D13C500]	01.2009-
VOLVO	FH 500 12.8	[D13C500]	05.2012-
VOLVO	FH 500 12.8	[D13C500]	09.2007-
VOLVO	FH 500 12.8	[D13K500]	05.2012-
VOLVO	FH 520 12.8	[D13A520]	09.2005-
VOLVO	FH 540 12.8	[D13C540]	01.2009-
VOLVO	FH 540 12.8	[D13C540]	05.2012-
VOLVO	FH 540 12.8	[D13K540]	05.2012-
VOLVO	FH II 500 12.8	[D13C500]	05.2012-
VOLVO	FH II 500 12.8	[D13K500]	05.2012-
VOLVO	FM 12/340 12.1	[D12D340]	08.1998-09.2005
VOLVO	FM 12H/340 12.1	[D12D340]	08.1998-09.2005
VOLVO	FM 12H/420 12.1	[D12D420]	08.1998-09.2005
VOLVO	FM 360 12.8	[D13A360]	09.2005-
VOLVO	FM 360 12.8	[D13A360]	11.2005-
VOLVO	FM 360 12.8	[D13B360]	09.2005-
VOLVO	FM 360 12.8	[D13B360]	11.2005-
VOLVO	FM 380 12.8	[D13C380]	04.2012-
VOLVO	FM 380 12.8	[D13C380]	09.2005-
VOLVO	FM 400 12.8	[D13A400]	09.2005-
VOLVO	FM 400 12.8	[D13B400]	09.2005-
VOLVO	FM 420 12.8	[D13C420]	04.2012-
VOLVO	FM 420 12.8	[D13C420]	09.2005-
VOLVO	FM 420 12.8	[D13K420]	04.2012-
VOLVO	FM 420 12.8	[D13K420]	06.2016-
VOLVO	FM 440 12.8	[D13A440]	09.2005-
VOLVO	FM 440 12.8	[D13B440]	09.2005-
VOLVO	FM 460 12.8	[D13C460]	04.2012-
VOLVO	FM 460 12.8	[D13C460]	05.2009-
VOLVO	FM 460 12.8	[D13C460]	09.2005-
VOLVO	FM 460 12.8	[D13K460]	04.2012-
VOLVO	FM 460 12.8	[D13K460]	05.2009-
VOLVO	FM 460 12.8	[D13K460]	06.2016-
VOLVO	FM 480 12.8	[D13A480]	09.2005-
VOLVO	FM 500 12.8	[D13C500]	04.2012-
VOLVO	FM 500 12.8	[D13C500]	09.2005-
VOLVO	FM 500 12.8	[D13K500]	04.2012-
VOLVO	FM 500 12.8	[D13K500]	06.2016-
VOLVO	FMX 380 12.8	[D13C380]	01.2011-
VOLVO	FMX 380 12.8	[D13C380]	01.2012-
VOLVO	FMX 380 12.8	[D13C380]	04.2010-
VOLVO	FMX 380 12.8	[D13C380]	09.2013-
VOLVO	FMX 420 12.8	[D13C420]	01.2011-
VOLVO	FMX 420 12.8	[D13C420]	01.2012-
VOLVO	FMX 420 12.8	[D13C420]	09.2013-
VOLVO	FMX 420 12.8	[D13K420]	06.2016-
VOLVO	FMX 420 12.8	[D13K420]	09.2013-
VOLVO	FMX 460 12.8	[D13C460]	01.2011-
VOLVO	FMX 460 12.8	[D13C460]	01.2012-
VOLVO	FMX 460 12.8	[D13C460]	04.2010-
VOLVO	FMX 460 12.8	[D13C460]	09.2013-
VOLVO	FMX 460 12.8	[D13K460]	06.2016-
VOLVO	FMX 460 12.8	[D13K460]	09.2013-
VOLVO	FMX 500 12.8	[D13C500]	01.2011-
VOLVO	FMX 500 12.8	[D13C500]	01.2012-
VOLVO	FMX 500 12.8	[D13C500]	09.2013-
VOLVO	FMX 500 12.8	[D13K500]	06.2016-
VOLVO	FMX 500 12.8	[D13K500]	09.2013-
VOLVO	FMX 540 12.8	[D13C540]	01.2011-
VOLVO	FMX 540 12.8	[D13K540]	06.2016-
VOLVO	FMX 540 12.8	[D13K540]	09.2013-

85020793 7420714203 M009T62171AM M9T62174AM 7485013211 114872 21632127 S24MH0109A2 7421632125 M009T66373AM M9T66373 M9T66372 M9T62171 M9T66371 M9T66372AM 7485020794 22602940 811.502.123 85000677 M9T62173 M9T62172 0001261049 M9T62174 811.516.123 CST35669GS CST35669OS 6035669 20431073 85013089 M009T62174 5001866293 88213893 M009T62172 M009T62173 CST35669AS M009T62171 20714203 CS1472 M009T66371 M009T66372 M9T62171AM M009T62172AM M009T66373 CST35669RS M9T66371ZZ9 7422602941 130-90120 MS1-401A 255259M STRL902 M9T64171 CST35631RS 255259P M9T66373AM CST35631AS STR5326 811.516.123.310 20891242 M009T64171ZT M009T64171AM 8178 220558 20430564 45-4127 85000746 M009T64171 M9T61171 M9T62172AM M90R3558SE CST35631ES M009T62173AM 6035631 5135147 S24MH0109 LRS2455 CST35669 M009T66371AM 19081028 M9T64171ZT 85000087 20437136OE M9T64171AM 19081015 M009T66371ZZ9 19928N CST35669ES CST35631GS M9T62173AM M009T62174AM LRS02455 CST35631OS CST35631 M009T66372AM M9T66371AM UD11990S M009T61171 21632125 MITM9T66371 220563 8EA012586-291 M90R3547SE 101388V STR71227 S5214 20572417

S5214
