Associated Numbers
M002T55871 M2T55871 STM5550 UD11141SSpecifications
Kilowatt | 2.2 kW |
Length (L.1) | 240 mm |
Mount Hole Center - Center (O.1) | 143 mm |
Mount Hole Center - Center (O.2) | 105 mm |
Mount Hole Center - Center (O.3) | 104 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
Mount Hole Diameter (C.3) | 13 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 22 mm |
Rotation | CW |
Spigot Diameter (A) | 100 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Various Models | [4DR5] |
Reference Information
M002T55871 STM5550 UD11141S STRE518 M2T55871Video/Publications
M002T55871 M2T55871 STM5550 STRE518 UD11141SAdd Your Number
