Associated Numbers
028000-1861 028000-3730 028000-6510 028000-6511 028000-8387 028000-8730 028000-9090 028000-9091 110402 11782 128000-1861 128000-1862 128000-1863 128000-3641 180.008.092 20387 20500514 20758 26-1125 30514R 31100-78611 31100-79610 31100-79611 31100-79650 31100-79660 31100-79661 31100-79680 31100-79X50 31100-85291 455902 6040102 88212835 9751 AES5114 CST40102 CST40102AS CST40102ES CST40102GS CST40102OS CST40102RS DRS3098 DS4208 J5218002 JS387 LRS00514 LRS514 S5170 STN2387 STR70008 UD02212SSpecifications
Kilowatt | 0.8 kW |
Length (L.1) | 235 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 8 qty |
No./Teeth (Replaces) | 8 qty |
Pinion at Rest (B) | 26 mm |
Rotation | ACW |
Spigot Diameter (A) | 65 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SUZUKI | Carry 0.8 | [F8A] | 11.1980-10.1985 |
SUZUKI | Super Carry 1.0 | [F10A] | 10.1985-03.1999 |
SUZUKI | Super Carry 1.0 | [F10A] | 10.1992-03.1999 |
Reference Information
028000-6510 028000-6511 311007966 3Z216 20500514 6040102 31100-79680 11782 455902 003-Z216 MAV5900 028000-1861 028000-8730 UD02212S 9751 128000-3641 31100-85291 31100-7966 20387 028000-3730 128000-1862 128000-1861 DS4208 M002T40271 3110085010 128000-1863 31100-85010 3.70801E+11 JS387 LRS514 31100-79650 AES5114 ANM15318X 31100-79611 3110079610L 028000-8387 31100-79610 110402 CST40102ES QD1226CG STRS070 CST40102AS J5218002 31100-85020 3110085021 MTZ216 20758 CST40102 335237 31100-79X50 31100-79660 30514R 31100-79661 STN2387 CST40102RS 3110079620 3110079X50000 STR70008 88212835 31100-78611 LRS00514 31100-79620 31100-79621 26-1125 ALT131110 S5170 CGB-23098 3110079621 180.008.092 3110079628 028000-9091 PRSS070 31100-79630 028000-9090 CST40102OS 3110079630 M2T40271 CST40102GS 31100-79631 DRS3098Video/Publications
003-Z216 028000-1861 028000-3730 028000-6510 028000-6511 028000-8387 028000-8730 028000-9090 028000-9091 110402 11782 128000-1861 128000-1862 128000-1863 128000-3641 180.008.092 20387 20500514 20758 26-1125 30514R 31100-78611 31100-79610 31100-79611 31100-79650 31100-79660 31100-79661 31100-79680 31100-79X50 31100-85291 3Z216 455902 6040102 88212835 9751 AES5114 ALT131110 CGB-23098 CST40102 CST40102AS CST40102ES CST40102GS CST40102OS CST40102RS DRS3098 DS4208 J5218002 JS387 LRS00514 LRS514 MAV5900 MTZ216 S5170 STN2387 STR70008 STRS070 UD02212SAdd Your Number
