Associated Numbers
114343 20493306OE 254254 28.3031 36100-72000 6032603 CST32603GS M004T95071 M004T95072 M004T95076 M004T95082 M4T95071 M4T95072 M4T95076 M4T95082 S5164 STR9106 UD02157SSpecifications
| Kilowatt | 7.5 kW |
| Length (L.1) | 385 mm |
| Mount Hole Center - Center (O.1) | 135 mm |
| Mount Hole Center - Center (O.2) | 118 mm |
| Mount Hole Center - Center (O.3) | 118 mm |
| Mount Hole Diameter (C.1) | 13 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| Mount Hole Diameter (C.3) | 13 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| No./Teeth (Replaces) | 13 qty |
| Pinion at Rest (B) | 58.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 100 mm |
| Unit Type | MITSUBISHI |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MITSUBISHI | Fuso 305 | ||
| MITSUBISHI | Fuso 310 | ||
| MITSUBISHI | Fuso 320 | ||
| MITSUBISHI | Fuso 355 | ||
| MITSUBISHI | Fuso 8DC9 | ||
| MITSUBISHI | Fuso V8 |
Reference Information
28.3031 M005T50081 STRF836 S5164 CST32603GS M005T57873 M5T80086 23300J5500 ME090543 M4T95082 ME067695 M5T55072 M5T55071 M005T27871 MG2700000 M005T50071 20493306OE M5T57873 254254 STR9106 23300J5508 114343 M004T95082 3126600023 220617 M005T27281 ME067671 ME067433 M004T95072 M004T95071 UD02157S ME067672 M004T95076 M7T05071 ME067677 6032603 M5T50081 ME060401 36100-72000 ME065737 M5T27281 M4T95071 M4T95072 M007T05071 M005T55072 M005T55071 M4T95076 M5T27871 M005T80086 M5T50071Video/Publications
114343 20493306OE 254254 28.3031 36100-72000 6032603 CST32603GS M004T95071 M004T95072 M004T95076 M004T95082 M4T95071 M4T95072 M4T95076 M4T95082 S5164 STR9106 STRF836 UD02157S 220617Add Your Number
