Associated Numbers
130-80180 M008T85671 M8T85671 ME193062 STM5671 UD02146SSpecifications
Kilowatt | 3.7 kW |
Length (L.1) | 241 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 10 mm |
Rotation | CW |
Spigot Diameter (A) | 77 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Engine | [4M41] |
Reference Information
130-80180 STM5671 M8T85671 ME193062 UD02146S M008T85671Video/Publications
130-80180 M008T85671 M8T85671 ME193062 STM5671 UD02146SAdd Your Number
