Associated Numbers
113618 12085 17754N 17866N 20437561BN 22.3209 25-3057 254163 56041207 56041207AB 56041207AC 56041207AD 6035165 AEY1560 CST35165AS DRS0218 LRS01560 M000T91181 M000T91181ZC M000T91182 M000T91182ZC M001T84981 M001T84981ZC M0T91181 M0T91181ZC M0T91182 M0T91182ZC M1T84981 M1T84981ZC S1127M S5127 STR71154Specifications
Kilowatt | 1.6 kW |
Length (L.1) | 216 mm |
Mount Hole Center - Center (O.1) | 117.5 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 5 mm |
Rotation | CW |
Spigot Diameter (A) | 65 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JEEP | Grand Cherokee 4.7 Laredo | 01.2000- | |
JEEP | Grand Cherokee 4.7 Limited | 01.2000- | |
JEEP | Grand Cherokee 4.7 V8 | [EVA] | 08.2000- |
Reference Information
RL041207AC 17866N 20437561BN LRS1560 56041207 113618 56041207B 56041207A M000T91181ZC M0T91182ZC STR5073 M000T91182ZC M0T91181ZC STRL161 DRS0218 LRS01560 MAV371650 KRL041207AC M001T84981 STR71154 MT91182 S5127 17754N M000T91181 M000T91182 AEY1560 56041207ZC 56041207AD 12085 M1T84981ZC 254163 M001T84981ZC K56041207AE ANM12438X 25-3057 6035165 M0T91182 M1T84981 STRS343 M0T91181 335150 CST35165AS 56041207AB 56041207AC 22.3209 S1127MVideo/Publications
113618 12085 17754N 17866N 20437561BN 22.3209 25-3057 254163 56041207 56041207AB 56041207AC 56041207AD 6035165 AEY1560 CST35165AS DRS0218 LRS01560 LRS1560 M000T91181 M000T91181ZC M000T91182 M000T91182ZC M001T84981 M001T84981ZC M0T91181 M0T91181ZC M0T91182 M0T91182ZC M1T84981 M1T84981ZC MAV371650 S1127M S5127 STR71154 STRL161 STRS343Add Your Number
