Associated Numbers
04609345 114328 17726N 22.3246 25-4078 254149 4609345 DRS0578 EAA-121664 LRS02406 M001T84181 M001T84181ZC M1T84181 M1T84181ZCSpecifications
Kilowatt | 1.6 kW |
Length (L.1) | 243 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Center - Center (O.2) | 71 mm |
Mount Hole Center - Center (O.3) | 68 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 9 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | 300 M 2.7 V6 24V | [EER] | 08.2000-09.2004 |
CHRYSLER | 300 M 2.7 V6 24V | [EER] | 11.1998-08.2000 |
CHRYSLER | Concorde 2.7 LX | [EER] | 10.1997-09.2003 |
Reference Information
4609345 M001T84181 22.3246 331758 LRS2406 17726N EAA-121664 STR5314 114328 M1T84181 254149 ANM12798X M001T84181ZC DRS0578 25-4078 LRS02406 M1T84181ZCVideo/Publications
04609345 114328 17726N 22.3246 25-4078 254149 DRS0578 EAA-121664 LRS02406 LRS2406 M001T84181 M001T84181ZC M1T84181 M1T84181ZCAdd Your Number
