Associated Numbers
112846 17559N 20437422BN 22.3162 25-2443 255068 4609058 6035224 CST35224 CST35224AS CST35224ES CST35224GS CST35224OS CST35224RS DRZ5184 EAA-121662 LRS01495 M001T78581 M001T78581ZC M1T78581 M1T78581ZCSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 231 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Center - Center (O.2) | 71 mm |
Mount Hole Center - Center (O.3) | 68 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 8 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | CiRus 2.5 | [EEB] | 01.1998-01.1998 |
CHRYSLER | CiRus 2.5 | 01.1999-01.2000 | |
CHRYSLER | CiRus 2.5 LX | [EEB] | 01.1995-01.1997 |
CHRYSLER | CiRus 2.5 LX | [EEB] | 10.1994-09.2000 |
CHRYSLER | CiRus 2.5 LXI | [EEB] | 01.1995-01.1997 |
CHRYSLER | Sebring 2.5 JX | [EEB] | 01.1996-01.1997 |
CHRYSLER | Sebring 2.5 JX | [EEB] | 01.1998-01.1998 |
CHRYSLER | Sebring 2.5 JX | 01.1999-01.2000 | |
CHRYSLER | Sebring 2.5 JXI | [EEB] | 01.1996-01.1997 |
CHRYSLER | Sebring 2.5 JXI | [EEB] | 01.1998-01.1998 |
CHRYSLER | Sebring 2.5 JXI | 01.1999-01.2000 | |
CHRYSLER | Sebring 2.5 LE | [EEB] | 05.1995-09.2000 |
CHRYSLER | Sebring 2.5 LX | [EEB] | 01.1996- |
CHRYSLER | Sebring 2.5 LX | 01.1999-01.1999 | |
CHRYSLER | Sebring 2.5 LXI | [EEB] | 01.1996-01.1997 |
CHRYSLER | Sebring 2.5 LXI | [EEB] | 01.1998-01.1998 |
CHRYSLER | Sebring 2.5 LXI | 01.1999-01.1999 | |
DODGE | Stratus 2.5 | 01.1999-01.2000 | |
DODGE | Stratus 2.5 ES | [EEB] | 01.1995-01.1997 |
DODGE | Stratus 2.5 ES | [EEB] | 01.1998-01.1998 |
DODGE | Stratus 2.5 V6 | [EEB] | 12.1995-04.2001 |
Reference Information
4609058 17559N DRZ5184 M0T80481 112846 4671101 CST35224AS M1T78581ZC M1T78581 M001T78581ZC CST35224RS R4609058 CST35224OS ANM97404X 22.3162 LRS1495 CGB-28581 CST35224GS CST35224ES 336237 EAA-121662 20437422BN M001T78581 25-2443 LRS01495 255068 STR5144 M000T80481 6035224 STRF671 CST35224Video/Publications
112846 17559N 20437422BN 22.3162 25-2443 255068 4609058 6035224 CGB-28581 CST35224 CST35224AS CST35224ES CST35224GS CST35224OS CST35224RS DRZ5184 EAA-121662 LRS01495 LRS1495 M001T78581 M001T78581ZC M1T78581 M1T78581ZC STRF671Add Your Number
