Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 252.51 including GST
NZ$ 219.57 excluding GST
or four payments of $63.13
with
Learn More
each
S5119
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
M1T77777Associated Numbers
112845 17461N 25-3318 4609011 DRS0755 LRS01751 M001T77777 M001T77777ZC M001T77781 M001T77781ZC M1T77777 M1T77777ZC M1T77781 M1T77781ZC S1166MSpecifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 230 mm |
| Mount Hole Center - Center (O.1) | 69 mm |
| Mount Hole Center - Center (O.2) | 114 mm |
| Mount Hole Center - Center (O.3) | 71 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 8.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | Concorde 3.5 | 01.1993-01.1995 | |
| CHRYSLER | Concorde 3.5 LX | 01.1996-01.1997 | |
| CHRYSLER | Concorde 3.5 LXI | 01.1996-01.1997 | |
| CHRYSLER | LHS 3.5 | 01.1994-01.1997 | |
| CHRYSLER | New Yorker 3.5 | 01.1994-01.1996 | |
| CHRYSLER | Prowler 3.5 | 01.2001- | |
| DODGE | B100 3.7 | 01.1971-01.1971 | |
| DODGE | B100 3.7 | 01.1971-01.1979 | |
| DODGE | B100 3.7 | 01.1979-01.1980 | |
| DODGE | B100 3.7 Sportsman | 01.1971-01.1978 | |
| DODGE | B100 3.7 Sportsman | 01.1979-01.1980 | |
| DODGE | B100 5.2 | 01.1971-01.1971 | |
| DODGE | B100 5.2 | 01.1971-01.1980 | |
| DODGE | B100 5.2 | 01.1979-01.1980 | |
| DODGE | B100 5.2 Sportsman | 01.1971-01.1980 | |
| DODGE | B100 5.2 Sportsman | 01.1979- | |
| DODGE | B100 5.9 | 01.1971-01.1978 | |
| DODGE | B100 5.9 | 01.1974- | |
| DODGE | B100 5.9 Sportsman | 01.1972-01.1978 | |
| DODGE | B100 5.9 Sportsman | 01.1974- | |
| DODGE | B100 7.2 | 01.1974- | |
| DODGE | B150 3.7 | 01.1981-01.1982 | |
| DODGE | B150 3.7 | 01.1983-01.1987 | |
| DODGE | B150 3.7 Sportsman | 01.1981-01.1982 | |
| DODGE | B150 3.7 Sportsman | 01.1983-01.1987 | |
| DODGE | B150 5.2 | 01.1981-01.1982 | |
| DODGE | B150 5.2 | 01.1983-01.1987 | |
| DODGE | B150 5.2 Sportsman | 01.1981-01.1982 | |
| DODGE | B150 5.2 Sportsman | 01.1983-01.1987 | |
| DODGE | Intrepid 3.5 | 01.1993-01.1997 | |
| DODGE | Intrepid 3.5 ES | 01.1993-01.1997 | |
| EAGLE | Vision 3.5 | 01.1993-01.1997 | |
| EAGLE | Vision 3.5 ESI | 01.1995-01.1997 | |
| PLYMOUTH | Prowler 3.5 | 01.1997-01.1997 | |
| PLYMOUTH | Prowler 3.5 | 01.1999-01.1999 |
Reference Information
| 112845 | CARGO |
| 17461N | WAI / TRANSPO |
| 25-3318 | ELSTOCK |
| 4609011 | CHRYSLER |
| DRS0755 | DELCO |
| F032112845 | CARGO |
| LRS01751 | LUCAS |
| LRS1751 | LUCAS |
| M001T77777 | MITSUBISHI |
| M001T77777ZC | MITSUBISHI |
| M001T77781 | MITSUBISHI |
| M001T77781ZC | MITSUBISHI |
| M1T77777 | MITSUBISHI |
| M1T77777ZC | MITSUBISHI |
| M1T77781 | MITSUBISHI |
| M1T77781ZC | MITSUBISHI |
| S1166M | PRESTOLITE |
| STR5421 | ELECTROLOG |
| STRS431 | 3EFFE |
Video/Publications
