Associated Numbers
04868860AA 113977 20437702BN 22.1482M 22.3230 25-4028 254394 254394M 32716N 4868860AA 6035207 88214294 AEY2356 CST35207AS CST35207GS DRS0095 EAA-121940 LRS02356 M002T88971 M2T88971 S5099 SS717Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 251 mm |
| Mount Hole Center - Center (O.1) | 113 mm |
| Mount Hole Center - Center (O.2) | 71 mm |
| Mount Hole Center - Center (O.3) | 68 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 10 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | Voyager 2.8 CRD | [ENR] | 06.2004- |
| CHRYSLER | Voyager 2.8 CRD | 10.2007- | |
| CHRYSLER | Voyager 2.8 CRDi | [ENS] | 10.2007- |
| DODGE | Caravan IV 2.8 CRD | [ENS] | 01.2009- |
| DODGE | Grand Caravan 2.8 CRD | 01.2008- |
Reference Information
SS717 254394 254394M 113977 220711 04838860AA 4688860AA M002T88971ZC LRS02356 CST35207AS STRS235 336150 K04868860AA DRS0095 22.1482M LRS2356 88214294 S5099 AEY2356 M002T88971 04868860AA EAA-121940 STR5148 5035141 20437702BN M2T88971ZC 22.323 CST35207GS 32716N CS1482 ANM12315X 25-4028 4868860AA M2T88971 6035207 RNLM2T88971Video/Publications
04868860AA 113977 20437702BN 22.1482M 22.3230 25-4028 254394 254394M 32716N 6035207 88214294 AEY2356 CS1482 CST35207AS CST35207GS DRS0095 EAA-121940 LRS02356 LRS2356 M002T88971 M2T88971 RNLM2T88971 S5099 SS717 STRS235 220711Add Your Number
