Associated Numbers
0986016451 0986017571 111696 12033 17142N 17171N 201092 20437442BN 20500722 22.1092 25-1230 31100-64B12 31100-64B13 31100-86030 31100-86032 31100-86033 31100-860D2 458477 6035244 8052811 8212149 88212149 8EA737454-001 CST35244 CST35244AS CST35244ES CST35244GS CST35244OS CST35244RS CST40114AS DRS3746 EAA-121600 JS1092 M0T86481 M1T70281 M1T70281ZC M1T70283 M1T70283ZC M1T75283 M1T87081 STR71062Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 208 mm |
Mount Hole Center - Center (O.1) | 101 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 8 qty |
No./Teeth (Replaces) | 8 qty |
Pinion at Rest (B) | 6 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SUZUKI | Alto 1.0 | [G10B] | 09.1994-06.2002 |
SUZUKI | Baleno 1.6 i 16V | [G16B] | 07.1995-05.2002 |
SUZUKI | Baleno 1.6 i 16V 4WD | [G16B] | 07.1995-05.2002 |
SUZUKI | Baleno 1.8 GT | [J18A] | 03.1996-05.2002 |
SUZUKI | Baleno 1.8 i 16V | [J18A] | 08.1996-05.2002 |
SUZUKI | Baleno 1.9 TD | [XUD9] | 04.1998-05.2002 |
SUZUKI | Swift 1.0 | [G10] | 10.1983-03.1989 |
SUZUKI | Swift 1.0 | [G10A] | 03.1984-12.2004 |
SUZUKI | Swift 1.3 | [G13A] | 03.1989-08.1996 |
SUZUKI | Swift 1.3 | [G13A] | 10.1984-03.1989 |
SUZUKI | Swift 1.3 | [G13B] | 09.1991-12.1995 |
SUZUKI | Swift 1.3 GTi | [G13B] | 03.1989-05.2001 |
SUZUKI | Swift 1.3 GXi | [G13B] | 08.1986-03.1989 |
SUZUKI | Swift 1.6 | [G16B] | 11.1989-12.1991 |
SUZUKI | Swift 1.6 4WD | [G16B] | 11.1989-12.1991 |
SUZUKI | Swift 1.6 i | [G16B] | 09.1991-09.1995 |
SUZUKI | Swift 1.6 i 4WD | [G16B] | 09.1991-09.1995 |
SUZUKI | Wagon R+ 1.3 4WD | [G13BB] | 10.2001- |
Reference Information
S5040 M001T70281ZC 003-Z252 M001T87081 8212149 12033 M001T70283ZC M001T70281 3110064B11 M001T70283 3.11009E+12 22.1092 3Z252 3Z212 CGB-23376 31100-64B13 458477 31100-64B11 003-Z212 31100-64B12 CST35244RS M1T70281 M1T70283 CST35244ES MAV6070 M1T87081 CST35244AS JS1092 20500722 17171N 986017571 20437442BN M0T86481 220196 201092 M1T70283ZC 31100-86032 111696 31100-86030 M1T70281ZC M000T86481 31100-86033 MTZ212 986016451 M001T75281 17142R M001T75283 DRS3746 3110064B12000 S12MH0335A2 000986016451 8EA737454-001 17142N STRL722 STR5072 CST35244OS 5035748 CST35244GS 8052811 EAA-121600 31100-82641 25-1230 MTZ252 31100-860D2 3110064B13000 6035244 88212149 STR71062 000986017571 ANM15966X M1T75283 CST35244 M1T75281Video/Publications
003-Z212 003-Z252 0986016451 0986017571 111696 12033 17142N 17171N 201092 20437442BN 20500722 22.1092 25-1230 31100-64B12 31100-64B13 31100-86030 31100-86032 31100-86033 31100-860D2 3Z212 3Z252 458477 6035244 8052811 8212149 88212149 8EA737454-001 CGB-23376 CST35244 CST35244AS CST35244ES CST35244GS CST35244OS CST35244RS DRS3746 EAA-121600 JS1092 M0T86481 M1T70281 M1T70281ZC M1T70283 M1T70283ZC M1T75283 M1T87081 MAV6070 MTZ212 MTZ252 S5040 STR71062 STRL722 220196Add Your Number
