S5034 - Brand new AS-PL Starter motor

Specifications

Kilowatt	0.9 kW
Length (L.1)	190 mm
Mount Hole Center - Center (O.1)	77.5 mm
Mount Hole Center - Center (O.2)	110.5 mm
Mount Hole Center - Center (O.3)	77 mm
Mount Hole Diameter (C.1)	M10x1.75 mm
Mount Hole Diameter (C.2)	11.5 mm
Mount Hole Diameter (C.3)	M10x1.75 mm
No./Mount holes	3 qty
No./Mount holes with thread	2 qty
No./Teeth	8 qty
No./Teeth (Replaces)	8 qty
Pinion at Rest (B)	16 mm
Rotation	CW
Spigot Diameter (A)	74 mm
Unit Type	MITSUBISHI
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
KIA	Clarus 1.8 i 16V	[T8]	07.1996-11.2001
KIA	Clarus 2.0 i 16V	[FE]	07.1996-
KIA	Pride 1.3	[B3]	08.1999-
KIA	Sephia 1.5 i 16V	[B5]	02.1996-12.1997
KIA	Sephia 1.6	[B6]	09.1993-12.1997
KIA	Sephia 1.6 i	[B6]	01.1995-12.1997
KIA	Sportage 2.0 i 16V 4WD	[FE]	04.1994-02.2001
KIA	Sportage 2.0 i 4WD	[FE]	04.1994-08.1999
MAZDA	121 1.3 16V	[B3]	11.1990-03.1996
MAZDA	323 1.3 16V	[B3]	10.1996-
MAZDA	323 1.3 16V	[B3ME]	05.1998-10.2000
MAZDA	323 1.5 16V	[ZL]	05.1998-01.2001
MAZDA	323 1.6	[B65M]	06.1987-10.1995
MAZDA	323 1.6	[B6E]	06.1987-10.1995
MAZDA	323 1.8 16V 4WD	[BP52]	09.1991-07.1994
MAZDA	323 1.8 4WD		06.1991-05.1994
MAZDA	323 F 1.6		01.2001-05.2004
MAZDA	323 F 1.8 16V	[BP31]	09.1989-03.1993
MAZDA	323 S 1.4	[B3]	01.2001-05.2004
MAZDA	323 S 1.6		01.2001-05.2004
MAZDA	B 2200 2.2	[F2L8]	08.1991-12.1996
MAZDA	Demio 1.3 16V	[B3]	08.1998-02.2003

Reference Information

STRW053 220118 M003T38882B M003T38882A M003T38882C AA30G-18-400 B593-18-400-9R MC109028 20437331BN CST35133OS EAA-111121 M3T38881A MB35918400A M3T33588 MC109021 22.1 LRS627 M3T33583 M3T38881C M3T33581 8505-18-400 M3T38881B M3T33582 OK900-18400B MAV371330 OK900-18400C M3T49381 0K24018400 0K900-18400C M003T24482 M003T24483 20513071 OK24018400 M3T30881 B6DK-18-400 B6S8-18-400 B30318400 8212160 FE5018400D M3T33582A 0B6S818400 S12MH0849A2 110808 986014991 PE24731100 ANM15799X S1225M E357-18-400 M43196 M003T38881 M3T49481 M003T38882 F802-18-400B F802-18-400A F802-18-400L M003T38885 MAV221220 0K90018400A M003T38883 0K90018400B M003T38884 0K90018400C B658-18-400 M003T33586D M3T24482A M3T24482J M3T24482K M3T24482L 16922N M003T49781 M3T24482H B676-18-400 M3T38882B M3T38882A 25-1114 M003T24486H DRS3579 M3T38882C M003T39981 20437331OE 8EA737191-001 B6S8-18-400A OK90018400 OK90018400B OK90018400C PE24-73-1100 11704 E356-48-400B 9658 22.1000M LRS2055 M3T49581 F802-18-400AT 3M193 M3T43581 8052313 CST35133RS OB6S818400 M003T49481 220387 B676-18-400A 201098 201098V B676-18-400B 0K90018400 CGB-23501 600058 MAV371280 FE5A-18-400A OK24118400B OK24118400C OK24118400A B315-18-400 M003T43581 LRS02055 CST35133AS M003T33582A F8B1-18-400AT 000986014991 F8B1-18-400 M3T24486H 20640 B505-18-400-9R M003T49581 F802-18-400 STR00246 OK95418400 STR5082 3M162 0K24118400 B35918400 B61P-18-400 M3T38881 OK240-18400 M3T38882 F240-18-400A MB30318400A F240-18-400B MTD212 CST35133GS 361002Y100 F240-18-400C M3T24482 0K95418400 M3T24483 M003T30881 M3T49781 B505-18-4009R FE5A-18-400 M3T24482HC MAV371290 STA0470R M3T39981 LRS1150 3D212 STR71005 0K24118400A 66925114 0K24118400C M003T33588 M3T38883 M3T38884 CGB-24991 M3T38885 M003T39481 000986018721 M003T33583 M003T33582 M003T33581 FE05-18-400C FE05-18-400B FE05-18-400A FE50-18-400E B593-18-400 MTM162 25-2057 6035133 B61P-18-400A E356-18-400 CST35133ES B505-18-400 F8B1-18-400B F8B1-18-400C OK24118400 M003T49381 003-D212 F8B1-18-400A M3T21874 B658-18-400R 986018721 36100-2Y100 E357-18-400A VS305 M3T38862 LRS00627 B630-18-400A M003T33283 M003T33282 M003Y24482 E356-18-400A LRS01150 E356-18-400B 201000 003-M162 F240-18-400 F210-18-400A CST35133 F210-18-400 S5034 B676-18-400AT M3T33282 M3T33283 M3Y24482 MAV6070 MC108027 B593184009R AES6127 MC108024 E356-18-400L 66925181 B630-18-400 JS1000 MAV6060 M003T21874 M003T24482HC B315-18-400B M3T39481 B315-18-400E M003T38881A M003T38881C M003T38881B B315-18-400A STRS188 25-2009 MTM193 201146 F806-18-400 S12MH0849 003-M193 M003T24482A M3T33586D M003T24482H M003T24482L M003T24482J M003T24482K

Video/Publications

003-D212 003-M162 003-M193 0986014991 0986018721 0B6S818400 0K90018400 110808 11704 16922N 201000 201098 201098V 20437331BN 20437331OE 20513071 20640 22.1000 22.1000M 25-1114 25-2009 25-2057 3D212 3M162 3M193 600058 6035133 66925114 66925181 8052313 8212160 8505-18-400 8EA737191-001 9658 AES6127 B505-18-400 B593-18-400 B676-18-400 B676-18-400A B676-18-400B B6S8-18-400 B6S8-18-400A CGB-23501 CGB-24991 CST35133 CST35133AS CST35133ES CST35133GS CST35133OS CST35133RS DRS3579 E356-48-400B EAA-111121 JS1000 LRS00627 LRS01150 LRS02055 LRS1150 LRS2055 LRS627 M003T21874 M3T21874 M3T30881 M3T38881 M3T38881A M3T38881B M3T38881C M3T38882 M3T38882A M3T38882B M3T38882C M3T43581 M3T49381 M43196 MAV221220 MAV371280 MAV371290 MAV371330 MAV6060 MAV6070 MB35918400A MC108024 MC108027 MC109021 MC109028 MTD212 MTM162 MTM193 OB6S818400 OK90018400 S1225M S5034 STR71005 STRS188 STRW053 VS305 220118 220387
