Associated Numbers
0986023590 101386M 113672 20437906OE 22.1386 255334M 255334P 28.1386M 30740N 438210 5001853713 5010306592 5010480196 5010508380 571.511.113 6035609 6035643 8121 860616 88212810 8823590 8EA738258-291 CS1386 CST35609 CST35609AS CST35609ES CST35609GS CST35609OS CST35609RS CST35643 CST35643AS CST35643ES CST35643GS CST35643OS CST35643RS EAA-121155 M009T60471 M009T61571 M90R3540SE M9T60471 M9T61571 STR71194Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 351 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Center - Center (O.2) | 126 mm |
Mount Hole Center - Center (O.3) | 126 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
No./Teeth (Replaces) | 11 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT V.I. | 270.18 11.1 | [DCi11-270] | 01.2001- |
RENAULT V.I. | 270.18 11.1 | [DCi11-270] | 01.2001-12.2001 |
RENAULT V.I. | 320.18 11.1 | [DCi11G] | 01.2001- |
RENAULT V.I. | 320.18 11.1 | [DCi11G] | 08.2000- |
RENAULT V.I. | 320.24 11.1 | [DCi11G] | 08.2000- |
RENAULT V.I. | 320.26 11.1 | [DCi11G] | 01.2001- |
RENAULT V.I. | 320.26 11.1 | [DCi11G] | 08.2000- |
RENAULT V.I. | 370.18 11.1 | [DCi11E] | 01.2001- |
RENAULT V.I. | 370.18 11.1 | [DCi11E] | 08.2000- |
RENAULT V.I. | 370.24 11.1 | [DCi11E] | 08.2000- |
RENAULT V.I. | 370.26 11.1 | [DCi11E] | 01.2001- |
RENAULT V.I. | 370.26 11.1 | [DCi11E] | 08.2000- |
RENAULT V.I. | 370.32 11.1 | [DCi11E] | 01.2001- |
RENAULT V.I. | 420.18 11.1 | [DCi11C] | 01.2001- |
RENAULT V.I. | 420.18 11.1 | [DCi11C] | 08.2000- |
RENAULT V.I. | 420.24 11.1 | [DCi11C] | 08.2000- |
RENAULT V.I. | 420.25 11.1 | [DCi11C] | 08.2000- |
RENAULT V.I. | 420.26 11.1 | [DCi11C] | 01.2001- |
RENAULT V.I. | 420.26 11.1 | [DCi11C] | 08.2000- |
RENAULT V.I. | 420.32 11.1 | [DCi11C] | 10.2001- |
RENAULT V.I. | 420.34 11.1 | [DCi11C] | 01.2001- |
RENAULT V.I. | Distribution 320.26D 11.1 | [dCi11G] | 08.2000- |
RENAULT V.I. | Distribution 370.26D 11.1 | [dCi11E] | 08.2000- |
Reference Information
M009T60471ZZ9 CST35609AS M9T61571 CST35643AS M90R3540SE CST35609ES 8EA738258-291 STR5172 CST35609RS STR71194 CST35643RS M009T60471AM M009T60473AM 88212810 255334M 28.1386M 571.511.113 255334P M9T60471 101386M M9T60473 220343 5010508380 CST35643ES MAV376090 860616 UD19536S 336381 5001853713 S24MH0084A2 438210 M009T61571AM M009T60473 M009T60471 6035609 M009T61571ZZ9 000986023590 CST35609GS EAA-121155 S5027 M9T60473AM 30740N M9T60471AM CGB-20124 8121 986023590 M009T61571 22.1386 20437906OE 5010480196 CST35609 STRS381 CS1386 8823590 CST35643GS M9T61571AM CST35609OS CST35643OS 113672 6035643 5010306592 CST35643 STRL315Video/Publications
0986023590 101386M 113672 20437906OE 22.1386 255334M 255334P 28.1386M 30740N 438210 5001853713 5010306592 5010480196 5010508380 571.511.113 6035609 6035643 8121 860616 88212810 8823590 8EA738258-291 CGB-20124 CS1386 CST35609 CST35609AS CST35609ES CST35609GS CST35609OS CST35609RS CST35643 CST35643AS CST35643ES CST35643GS CST35643OS CST35643RS EAA-121155 M009T60471 M009T61571 M90R3540SE M9T60471 M9T61571 MAV376090 S5027 STR71194 STRL315 STRS381 220343 UD19536SAdd Your Number
