Associated Numbers
151.501.093 201354 201354V 20437806BN 20553 254449 254631 45-1101 6035608 8160 88213128 8EA012586-261 AET0553 CST35608 CST35608AS CST35608ES CST35608GS CST35608OS CST35608RS JS553 LRS01843 LRS1843 M002T56871 M002T66871 M002T66872 M002T66873 M002T66881 M002T66882 M002T67871 M002T67872 M002T67873 M002T67881 M002T67883 M002T67884 M2T56871 M2T66871 M2T66872 M2T66873 M2T66881 M2T66882 M2T67871 M2T67872 M2T67873 M2T67881 M2T67883 M2T67884 ME017034 ME017035 ME017036 ME017056 ME017085 ME017088 ME017092 MEO17035 MEO17056 MEO17085 MG232415 S5008 STM0553 STM8553 STM9553 STN0553 STR6138 UD02135S 16-023Specifications
Kilowatt | 3.2 kW |
Length (L.1) | 250 mm |
Mount Hole Center - Center (O.1) | 144 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 17 mm |
Rotation | CW |
Spigot Diameter (A) | 60 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Canter 211 Diesel | [4D30A] | 11.1983- |
MITSUBISHI | Canter 3.3 D | [4D30] | 01.1983- |
MITSUBISHI | Canter 444 Diesel | [4D31] | 01.1987- |
MITSUBISHI | Canter 60 3.3 D | [4D31T] | 01.1984-12.1994 |
Reference Information
M002T66873 M002T66872 M002T67884 M002T67881 M002T66871 M002T67883 M002T67882 MG232415 ME017061 MEO17088 JS553 MEO17085 STRS651 MEO17089 151.501.093.780 151.501.093.460 UD02135S 36100-41010 MEO17005 LRS1843 S5008 36100-41011 36100-41012 151.501.093.265 STM0553 110576 M002T66882 M002T66881 PRSS651 45-1101 335403 000986023420 ME017056 MEO17036 ME017092 MEO17035 MEO17034 M2T67872 151.501.093.131 M2T67871 151.501.093.130 M2T67873 20553 6035608 CST35608AS 8EA726505-001 986023420 M003T67871 ME017005 8EA012586-261 MEO17061 ME017089 ME017088 ME017085 S24MH0127A2 STR5112 88213128 M2T66871 M2T67883 M2T67882 M2T67881 M2T66873 LRS01843 M2T66872 M2T67884 M002T67873 M3T67871 M002T67872 M002T67871 ME017036 STR6138 8160 ME017035 ME017034 3610041010 MEO17056 3610041011 M2T66882 M2T66881 151.501.093.510 20437806BNVideo/Publications
151.501.093.130 20437806BN 45-1101 6035608.0 8160 88213128 8EA012586-261 8EA726505-001 CST35608AS JS553 LRS01843 LRS1843 M002T66871 M002T66872 M002T66873 M002T67871 M002T67873 M002T67881 M002T67883 M002T67884 M2T66871 M2T66872 M2T66873 M2T67871 M2T67873 M2T67881 M2T67883 M2T67884 ME017036 ME017085 ME017088 ME017092 MEO17035 MEO17056 MEO17085 MG232415 S5008 STM0553 STR6138 UD02135S 220200 220620Add Your Number
