Associated Numbers
0001218019 0001218101 0001218163 0001218167 0001218767 0986013650 10370 10682 11.139.333 113134 25-1077 30131N 35259940 3591 42013650 436044 439638 4403249 455508 5001014230 570.513.093 573387 6010224 6015220 726058 7700301993 7700723189 7700730756 7700868184 7701381647 88212557 8EA726118-001 9108667 93178785 943251300010 944288136500 9562002 AES9140 AZE4564 CS370 CST10224 CST10224AS CST10224ES CST10224GS CST10224OS CST10224RS CST15220 CST15220AS CST15220ES CST15220GS CST15220OS CST15220RS D7R41 DRS3650 EAA-121367 IS9333 LRS00940 LRS940 M1301 MSR662 SG0084 STRB010 UD12411SSpecifications
Kilowatt | 2.2 kW |
Length (L.1) | 332 mm |
Mount Hole Center - Center (O.1) | 103 mm |
Mount Hole Center - Center (O.2) | 103 mm |
Mount Hole Center - Center (O.3) | 146 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 25 mm |
Rotation | CW |
Spigot Diameter (A) | 110 mm |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Arena 2.5 D | [25DG] | 01.1997-12.2001 |
OPEL | Arena 2.5 D | [25DM] | 01.1997-12.2001 |
OPEL | Arena 2.5 D | [S8U780] | 03.1998-08.2001 |
RENAULT | Master 28-35 2.4 D | [8140.61.2300] | 08.1980-08.1989 |
RENAULT | Master 28-35 2.4 D | [S8U731] | 08.1980-08.1989 |
RENAULT | Master 28-35 2.5 D | [8140.61.2300] | 09.1980-07.1998 |
RENAULT | Master 28-35 2.5 D | [8140.67.2510] | 08.1989-07.1998 |
RENAULT | Master 28-35 2.5 D | [S8U731] | 09.1980-07.1998 |
RENAULT | Master 28-35 2.5 D | [S8U742] | 08.1989-07.1998 |
RENAULT | Master 28-35 2.5 TD | [8140.27.2580] | 08.1989-07.1998 |
RENAULT | Master 28-35 2.5 TD | [S9U702] | 08.1989-07.1998 |
RENAULT | Master 35 2.5 TD | [8140.27.2500] | 08.1989-07.1998 |
RENAULT | Master 35 2.5 TD | [8140.27.2510] | 08.1989-07.1998 |
RENAULT | Master 35 2.5 TD | [S9U714] | 08.1989-07.1998 |
RENAULT | Trafic 2.5 D | [8140.61.240] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D | [8140.67.2500] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D | [8140.67.2550] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D | [8140.67.2580] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D | [S8U720] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D | [S8U722] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D | [S8U750] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D | [S8U752] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D | [S8U758] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [8140.67.2500] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [8140.67.2580] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [814067.2500] | 08.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [814067.2580] | 08.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [S8U750] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [S8U750] | 08.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [S8U752] | 05.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [S8U752] | 08.1989-03.2001 |
RENAULT | Trafic 2.5 D 4x4 | [S8U758] | 08.1989-03.2001 |
RENAULT V.I. | B 110.45 2.8 | [8140.23.2565] | 09.1996-06.1999 |
RENAULT V.I. | B 110.45 2.8 | [8140.23.2585] | 09.1996-06.1999 |
RENAULT V.I. | B 120.35 2.8 | [8140.43.2585] | 09.1996-06.1999 |
RENAULT V.I. | B 120.55 2.5 | [8140.47.2585] | 01.1994-09.1996 |
RENAULT V.I. | B 120.55 2.8 | [8140.43.2585] | 09.1996-06.1999 |
RENAULT V.I. | B 120.65 2.5 | [8140.47.2585] | 01.1994-09.1996 |
RENAULT V.I. | B 120.65 2.8 | [8140.43.2585] | 09.1996-06.1999 |
RENAULT V.I. | B 70 2.4 D | [8140.61.235] | 01.1983-12.1990 |
RENAULT V.I. | B 80.35 2.5 | [8140.07.2530ID] | 09.1990-06.1999 |
RENAULT V.I. | B 80.35 2.5 | [8140.07.2585] | 09.1990-06.1999 |
RENAULT V.I. | B 80.35 2.5 | [8140.67.2585] | 09.1990-06.1999 |
RENAULT V.I. | B 80.45 2.5 | [8140.07.2530ID] | 09.1990-06.1999 |
RENAULT V.I. | B 80.45 2.5 | [8140.07.2585] | 09.1990-06.1999 |
RENAULT V.I. | B 80.45 2.5 | [8140.67.2585] | 02.1996-06.1999 |
RENAULT V.I. | B 80.45 2.5 | [8140.67.2585] | 09.1990-06.1999 |
RENAULT V.I. | B 90 2.4 D | [8140.21.235IDS] | 04.1986-09.1990 |
RENAULT V.I. | B 90 2.4 D | [8140.21.235IDS] | 08.1990-01.1992 |
RENAULT V.I. | B 90 2.5 D | [8140.27.2530IDS] | 08.1990-01.1992 |
VAUXHALL | Arena 2.5 D | [S8U758] | 03.1998-08.2001 |
VAUXHALL | Arena 2.5 D | [S8U780] | 03.1998-08.2001 |
VAUXHALL | Arena 2.5 D | [S8U782] | 03.1998-08.2001 |
Reference Information
1218767 11.139.333 0001218767 10370 CS370 7700723189 220038 726058 5010353 CST15220RS UD12411S 573387 CST10224RS MAV122240 7700868184 LRS940 S12BH0474A2 4737759 455508 1218163 6015220 7701381647 436044 1218167 IS9333 MSR662 11420 AES9140 9562002 9.44288E+11 CST10224AS 35259940 CST10224GS STRS081 0001218019 D7R41 M1301 CST10224 MS CST10224OS 8EA726118-001 CST15220ES 986013650 113134 0001218101 6010224 7700730756 9.43251E+11 5001014230 CST15220AS STRB010 4719666 110522 93178785 570.513.093 AZE4564 9108667 4400667 4713806 9111249 MAV321770 1218101 42013650 500325146 7700301993 CST15220 88212557 1218019 CST10224ES 439638 4403249 CST15220OS EAA-121367 MAV2090 STR00170 3591 R1040041 4755110 25-1077 CST15220GS SG0084 000986013650 1516752R 0001218163 665 4807376 10682 0001218167 DRS3650 LRS00940 MAV172200 30131NVideo/Publications
0001218019 0001218101 0001218163 0001218167 0001218767 0986013650 10370 10682 11.139.333 110522 113134 25-1077 30131N 35259940 3591 42013650 436044 439638 4403249 455508 5001014230 570.513.093 573387 6010224 6015220 726058 7700301993 7700723189 7700730756 7700868184 7701381647 88212557 8EA726118-001 9108667 93178785 943251300010 944288136500 9562002 AES9140 AZE4564 CS370 CS682 CST10224 CST10224AS CST10224ES CST10224GS CST10224OS CST10224RS CST15220 CST15220AS CST15220ES CST15220GS CST15220OS CST15220RS D7R41 DRS3650 EAA-121367 IS9333 LRS00940 LRS940 M1301 MAV122240 MAV172200 MAV2090 MAV321770 MS 665 MSR662 SG0084 STRB010 STRS081 UD12411S 220038Add Your Number
