Associated Numbers
113654 18941N 19083001 20404161BN 20419701OE 25-3377 254194 254194L 254194M 26.0006 2873K404 428000-1380 6021107 6030161 63280040 860714 8735R AEY2598 CST21107GS CST30161AS DRS0066 DRS0066N EAA-121074 LRS02206 RNL2873K404 S4029 STR52055 0740001000 Magneti Marelli 1000207612 Weidemann 1000256815 1000299578 11131014 Mahle show 11131228 11131606 11131780 11131946 11131964 11132035 11132344 11132474 11132481 11132483 11132534 Cargo 11445780 Claas 1235153 Clark 13130049 AES 18101195 Remy 2253148 Caterpillar 231095 253377 Elstock 254271 2872K404 Perkins 28738071 2873K621 2873K632 3127539 35263290 Prestolite 3575202 3644130 3680133M91 Massey Ferguson 3823621M1 4227442M91 Agco 4280001380 Denso 5269854 6215054M1 63280040010 6911913 Bobcat 700503103 PSH 7020620 702284 Manitou 71437150 JCB 71440533 781742 788129 91192512 Wilson 927405 944288183200 AZE4151 AZE4207 AZE4219 AZE4298 AZE4299 AZE4300 AZE4306 AZF4202 AZF4538 AZF4569 DRS0279 IS1195 Lucas LRS2598 MAHMS289 Wood Auto MS289 MSN8040 MSR8040 RNL RNL2873K404P RNL4280001380T RNLAZE4151 STR60617 STR70056 T400267 T400268 WOOSTR52055 WOOSTR60617Specifications
Kilowatt | 3 kW |
Length (L.1) | 292 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11.5 mm |
Mount Hole Diameter (C.2) | 11.5 mm |
Mount Hole Diameter (C.3) | 11.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 30.5 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MASSEY FERGUSON | MF 6270 | 01.1999- | |
MASSEY FERGUSON | MF 6280 | 01.1999- | |
MASSEY FERGUSON | MF 6290 | 01.1999- |
Reference Information
6030161.1 702284 113654 6030161.5 CST21107GS 3127539 S12MA0197A2 AZF4102 T400267 CGB-93404 20404161OE T400268 11.131.410 T410874 RNL2873K404 CST30161GS 700.503.103.090 MS289 STRL051 428000-1380 19083001 S4029 18941N-IK 20404161IT 220814 AZF4569 254194 2873K621 3784889M2 3784889M1 700.016.103.090 AZF4321 71437150 IS1071 4227442M91 MAV321610 11.131.070 20404161BN 63280040 AZE4199 11445780 700.503.103.510 788129 11.131.508 28738071 25-3377 11.131.228 DRS0066 781742 PRSL051 6911913 3823621M91 3823621M95 7020620 2873K404 3680133M91 18941R STR9017 AZF4264 11.131.973 LES0272 3575202 MSN8040 2253148 LRS2206 3586847 5269854 AZE4172 11.132.035 2873K632 700.503.103.050 11.131.606 11.131.964 63280040010 AZF4132 114387 ANM12286X 3667040M91 88213778 AZE4219 EAA-121074 700.503.103.265 DRS0066N MS111 3667040J9A 26.0006 116307 254194L MAV231060 254194M 225-3148 DRS0279 11.131.397 AZE4207 STR52055 CST30161AS 700.016.103.311 6021107.1 AEY2598 700.503.103.311 AZJ3369 AZE4151 CST30161IS MAV231070 6030161 20419701OE 11.132.175 11.131.946 LES272 18941N 860714 AZF4111 3784890M1 11.131.780 LRS02206Video/Publications
113654 114387 18941N 19083001 20404161BN 20419701OE 25-3377 254194 254194L 254194M 26.0006 2873K404 428000-1380 6021107 6030161 63280040 860714 8735R AEY2598 CGB-93404 CST21107GS CST30161AS DRS0066 DRS0066N EAA-121074 LRS02206 LRS2206 MAV231060 MAV231070 MAV321610 RNL2873K404 S4029 STR52055 STRL051 220814Add Your Number
