Associated Numbers
063101015010 0986024210 101192 101192H 10796 10796H 10796V 112382 11883 20500989 20513002 220024 25-3096 31397N 31397R 3829 42017030 455553 458407 46473785 46518059 46548653 46740242 500.582.103 6010331 6020150 6030107 63101015 63101018 63102020 71721222 726020 726133 7796598 88212784 8EA012526-741 8EA737823-001 AEU1192 CS1192 CST10331 CST10331AS CST10331ES CST10331GS CST10331OS CST10331RS CST20150 CST20150AS CST20150ES CST20150GS CST20150OS CST20150RS CST30107 CST30107AS CST30107ES CST30107GS CST30107OS CST30107RS DENDSN961 DRS3977 DS5087 DSN961 EAA-121172 G201192-A GS101015M-R GS101018-A LRS01586 MSN829 S4028 SG0139 SS602 STE1192 STR52025Specifications
Kilowatt | 0.8 kW |
Length (L.1) | 190 mm |
Mount Hole Center - Center (O.1) | 74 mm |
Mount Hole Center - Center (O.2) | 108 mm |
Mount Hole Center - Center (O.3) | 74 mm |
Mount Hole Diameter (C.1) | 6.5 mm |
Mount Hole Diameter (C.2) | 8.5 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 8 qty |
No./Teeth (Replaces) | 8. 10 qty |
OEM Product | No |
Pinion at Rest (B) | 12 mm |
Product Line | Standard Line |
Product Type | Brand new |
Rotation | CW |
Spigot Diameter (A) | 64 mm |
Unit Type | MAGNETI MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | Brava 1.2 16V | [182B2.000] | 12.1998-12.2002 |
FIAT | Bravo 1.2 16V | [182B2.000] | 12.1998-10.2001 |
FIAT | Palio 1.2 | [178B5.000] | 04.1996-02.2001 |
FIAT | Palio 1.2 | [178E2.000] | 06.1998- |
FIAT | Palio 1.2 | [188A4.000] | 02.2001- |
FIAT | Punto 1.2 | [176A8.000] | 10.1993-09.1999 |
FIAT | Punto 1.2 16V | [188A5.000] | 09.1999- |
FIAT | Punto 1.2 8V | [188A4.000] | 09.1999- |
FIAT | Punto 1.2 BiFuel | [188A4.000] | 08.2007- |
FIAT | Punto 1.2 Natural Power | [188A4.000] | 09.2003- |
FIAT | Siena 1.0 | 01.1998- | |
FIAT | Siena 1.2 | [188A5.000] | 01.2001- |
LANCIA | Y 1.2 | [188A4.000] | 03.1996-09.2003 |
LANCIA | Y 1.2 16V | [188A5.000] | 10.2000-09.2003 |
Reference Information
EAA-121172 DSN961 5030043 51833880 LRS01586 336430 20513002 STX200032R 63101018010 S12HT0009 NEU1192 71793780 71782351 500.544.083.058 55195030 71782353 55196400 20404701BN DENDSN961 500.582.103.080 7772859 63102020 S114-949 STX200032 0986024210 PRSS693 63102018 STR52025 S4028 STX200057R 8EA012526-741 S114949A CGB-53096 S114-949A 46740242 500.544.083.000 9.44281E+11 S12MA0009A2 46473785 CST30107AS 46429594 CS1192 STX200361 STRL126 STR9072 S114-901B 20404701RE 6030107 CST20150GS STRS700 DS4926N 7796598 51890633 112382 25-3096 STA0067R 71782288 500.582.103.270 500.544.083.265 6020150.1 500.582.103.275 STRS693 46548653 46548654 S12HT0009A2 8EA737823-001 ANM12413X AEU1192 63101018 20445051OE CST30107GS S114-903A 7622952 RAS34927 63101015 6030107.4 46518059 S114-903 46763529 6030107.1 STX200053R 20404701OE STM2016 LRS1586 STR3217 136910 500.582.103.050 S12MA0820A2 2506910 PRSS700 71794607 55201304 55201305 MSN400 STX200361R CST30107OS STE1192 46737560 31397N PRSL126 31397R S114949 71721222 DRS3816X STX200057 STX200053Video/Publications
