Associated Numbers
0986022111 101191 101345 101345V 11947 20404321 220693 25-2337 3004 32579R 42022111 458163 46451529 46531437 500.538.113 6030123 63111008 63111010 63111016 63111018 63111019 63111036 63111037 63223536 70789523 88212300 8EA012527-391 8EA737820-001 AEU1191 CS1191 CST30123 CST30123AS CST30123ES CST30123GS CST30123OS CST30123RS DRS3583 DRS3587 DS4693 DS4697 EAA-121400 LRS01431 S4027 SG0779 STE1191Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 212 mm |
Mount Hole Center - Center (O.1) | 106 mm |
Mount Hole Center - Center (O.2) | 72 mm |
Mount Hole Center - Center (O.3) | 73 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9. 11 qty |
Pinion at Rest (B) | 12 mm |
Rotation | CW |
Spigot Diameter (A) | 64 mm |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | Brava 1.6 16V | [182A4.000] | 02.1996-10.2001 |
FIAT | Brava 1.6 16V | [182A6.000] | 10.1995-10.2001 |
FIAT | Bravo 1.6 16V | [182A4.000] | 03.1996-10.2001 |
FIAT | Bravo 1.6 16V | [182A6.000] | 10.1995-10.2001 |
FIAT | Marea 1.6 100 16V | [182A4.000] | 09.1996-05.2002 |
FIAT | Marea 1.6 16V | [185A3.000] | 04.1997-02.1999 |
FIAT | Multipla 1.6 100 16V | [182A4.000] | 04.1999-06.2010 |
FIAT | Multipla 1.6 16V Bipower | [186A4.000] | 04.1999-06.2010 |
FIAT | Multipla 1.6 16V Blupower | [186A3.000] | 04.1999-06.2010 |
FIAT | Palio 1.6 16V | [178C7.098] | 07.1997-10.2003 |
FIAT | Palio 1.6 16V | [178D2.011] | 07.1997-10.2003 |
LANCIA | Dedra 1.6 16V | [182A4.000] | 01.1996-07.1999 |
LANCIA | Dedra SW 1.6 16V | [182A4.000] | 01.1996-07.1999 |
LANCIA | Lybra 1.6 16V | [182A4.000] | 07.1999-10.2005 |
Reference Information
46748349 220437 CST30123 7773763 CST30123RS 63223536 101191 101345V AEU1191 71723357 11947 STRL067 STR9015 986022111 51776205 CST30123AS DS4693 63111033 101345 51832956 63111036 DS4697 LRS1431 71782310 63111037 46748356 46748355 20404321 CST30123GS 51868757 46748350 CST30123OS 71782394 3004 458163 S12MA0821A2 46835094 8EA737820-001 71782309 S4027 71782308 ANM15803X 63111008 70789523 46531437 500.538.113 MAV2380 STA0174R 220693 46808152 46231536 46800152 55193407 71794531 25-2337 8EA012527-391 CS1191 71721272 DRS3587 32579R DRS3583 SG0779 71721236 63111010 63111019 STE1191 CST30123ES 71789523 6030123 46451529 63111016 63111018 EAA-121400 42022111 46524472 000986022111 46821681 46816971 LRS01431 71721266 MAV6360 88212300Video/Publications
0986022111 101191 101345 101345V 11947 20404321 220693 25-2337 3004 32579R 42022111 458163 46451529 46531437 500.538.113 6030123 63111008 63111010 63111016 63111018 63111019 63111036 63111037 63223536 70789523 88212300 8EA012527-391 8EA737820-001 AEU1191 CS1191 CST30123 CST30123AS CST30123ES CST30123GS CST30123OS CST30123RS DRS3583 DRS3587 DS4693 DS4697 EAA-121400 LRS01431 LRS1431 MAV2380 MAV6360 S4027 SG0779 STE1191 STRL067 220437Add Your Number
