Associated Numbers
063102003010 0986017781 10981 10981M 111420 11810 20510146 220179 25-2081 31160N 31160R 3825 42017781 458230 46419332 500.518.093 6030108 63102003 71721250 88212708 8EA012528-331 8EA737151-001 943102003010 944280177810 AES1246 CS981 CST30108 CST30108AS CST30108ES CST30108GS CST30108OS CST30108RS DRS3308 DS4418 EAA-121314 LRT00146 MRS17781 MSN603 MSR603 SG0130 STE0981 STR52005Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 207 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Center - Center (O.2) | 62 mm |
Mount Hole Center - Center (O.3) | 76 mm |
Mount Hole Diameter (C.1) | 8.5 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | 8.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 10.5 mm |
Rotation | CW |
Spigot Diameter (A) | 64 mm |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | Brava 1.4 | [182A5.000] | 10.1995-10.2001 |
FIAT | Brava 1.4 12V | [182A3.000] | 10.1995-08.1998 |
FIAT | Bravo 1.4 | [182A3.000] | 10.1995-10.2001 |
FIAT | Bravo 1.4 | [182A5.000] | 10.1995-10.2001 |
FIAT | Marea 1.4 80 12V | [182A3.000] | 09.1996-05.2002 |
Reference Information
20510146 CST30108RS DS4418 CST30108 220179 MSN603 EAA-121314 AES1246 LRT00146 CST30108AS MSR603 986017781 DRS3308 SG0130 CS981 MRS17781 71721250 000986017781 458230 STE0981 6030108 CST30108ES CST30108GS 63102003010 46231541 500.518.093 46419392 111420 10981M CST30108OS STRS022 63102003 46419332 9.4428E+11 3825 42017781 31160N 31160R 88212708 10981 8EA737151-001 25-2081 STR52005 STR90007 11810 9.43102E+11 8EA012528-331 MAV2000Video/Publications
063102003010 0986017781 10981 10981M 111420 11810 20510146 220179 25-2081 31160N 31160R 3825 42017781 458230 46419332 500.518.093 6030108 71721250 88212708 8EA012528-331 8EA737151-001 943102003010 944280177810 AES1246 CS981 CST30108 CST30108AS CST30108ES CST30108GS CST30108OS CST30108RS DRS3308 DS4418 EAA-121314 LRT00146 MAV2000 MRS17781 MSN603 MSR603 SG0130 STE0981 STR52005 STRS022Add Your Number
