Associated Numbers
115745 130.562.092 20479321 25-4181 254602 254602V 438274 458446 55564374 6015123 88214472 CST15123 CST15123AS CST15123ES CST15123GS CST15123OS CST15123RS DRS0525 DS1635 LRS02509 STV3198 TS22E20 UD20499S UNIT BOM 108-3491 VAL438274 47-311 vxs919 70-3141 SNV021 SNV021GQ
115745 Cargo
130562092 PSH
14130200 AES
195198 Valeo
254181 Elstock
438274 Valeo show
458446 Valeo show
55564374 Opel
A195198A Valeo
DRS0525 Remy
LRS02509 Lucas
LRS2509 Lucas
STR54171 Wood Auto
TS22E20 Valeo show
VAL438274 Wood Auto
VALTS22E20 Wood Auto
Specifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 216 mm |
| Mount Hole Center - Center (O.1) | 123 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 21 mm |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Trans Blazer 2.8 CDTi | [XLD28] | 01.2012- |
Reference Information
CST15123GS STV3198 CST15123AS S3186S STR0106 CST15123ES 6015123 STRS536 254602 55564374 20479321 CST15123OS CST15123 BOM TS22E20 UNIT DS1635 88214472 220540 LRS2509 115745 108-3491 DRS0525 254602V 438274 ANM12745X 130.562.092 UD20499S LRS02509 25-4181 CST15123RS 458446 VAL438274Video/Publications
115745 130.562.092 20479321 25-4181 254602 254602V 438274 458446 55564374 6015123 88214472 CST15123 CST15123AS CST15123ES CST15123GS CST15123OS CST15123RS DRS0525 DS1635 LRS02509 LRS2509 STRS536 STV3198 TS22E20 UD20499S UNIT BOM 108-3491 VAL438274 220540Add Your Number
