Associated Numbers
130-80501 18485N 18485R 20493021 241-30101 254345 6032120 6676958 6685191 830.550.103 88213665 91-31-9007 91-31-9007N CST32120 CST32120AS CST32120ES CST32120GS CST32120OS CST32120RS S-80084 STA3735 STR75005 TM000A29001 UD14944SSpecifications
Kilowatt | 3 kW |
Length (L.1) | 288 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BOBCAT | 773F | [V2203-EB] | 01.1999-12.1999 |
BOBCAT | 773G | [V2203-EB] | 01.1999-12.2002 |
BOBCAT | 773TG | [V2203T-EB] | 01.1999-12.2006 |
BOBCAT | 773 TurboG | [V2203T-EB] | 01.1999-12.2002 |
BOBCAT | 773 TurboG 500K | [V2203T-EB] | 01.2001-12.2001 |
BOBCAT | 863F | [BF4M1011] | 01.1999-12.1999 |
BOBCAT | 863G | [BF4M1011] | 01.1999-12.2006 |
BOBCAT | 863HF | [BF4M1011] | 01.1996-12.1999 |
BOBCAT | 863HG | [BF4M1011] | 01.1999-12.2006 |
BOBCAT | 864F | [BF4M1011F] | 01.1999-12.1999 |
BOBCAT | 864G | [BF4M1011F] | 01.1999-12.2001 |
BOBCAT | 864HG | [BF4M1011F] | 01.1999-12.2001 |
BOBCAT | A220 | [BF4M1011F] | 01.2001-12.2007 |
BOBCAT | A300 | [BF4M1011F] | 01.2002-12.2007 |
BOBCAT | T200 | [BF4M1011F] | 01.1999-12.2002 |
Reference Information
20493021 STRW355 STR0483 6685191 CST32120RS 6676958 241-30101 254345 CGB-28901 88213665 CST32120 91-31-9007 S-80084 TM000A29001 18485R 91-31-9007N 6032120 130-80501 UD14944S STA3735 18485N CGB-26958 830.550.103 CST32120OS CST32120AS STR75005 CST32120GS CST32120ESVideo/Publications
130-80501 18485N 18485R 20493021 241-30101 254345 6032120 6676958 6685191 830.550.103 88213665 91-31-9007 91-31-9007N CGB-26958 CGB-28901 CST32120 CST32120AS CST32120ES CST32120GS CST32120OS CST32120RS S-80084 STA3735 STR75005 STRW355 TM000A29001 UD14944SAdd Your Number
