Associated Numbers
19090N 201-12109 25-5317 256104 36100-2G100 849500 91-20-3559 91-20-3559N FS14N1 LRS04154 S-1513 STR80178 STV9090 STV9091 UD13972SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 180 mm |
Mount Hole Center - Center (O.1) | 94 mm |
Mount Hole Diameter (C.1) | M10x1.75 mm |
Mount Hole Diameter (C.2) | M10x1.75 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Embera 2.4 | [G4KC] | 01.2005-12.2009 |
HYUNDAI | NF 2.4 | [G4KC] | 01.2005-12.2009 |
HYUNDAI | Santa Fe 2.4 | [G4KE] | 01.2010- |
HYUNDAI | Santa Fe 2.4 4x4 | [G4KE] | 01.2010- |
HYUNDAI | Santa Fe 2.4 CCVT | 01.2012- | |
HYUNDAI | Sonata 2.4 | [G4KC] | 01.2005-12.2008 |
HYUNDAI | Sonata 2.4 | [G4KC] | 01.2008-12.2009 |
KIA | K5 2.4 | [G4KJ] | 01.2010- |
KIA | Optima 2.4 | [G4KJ] | 01.2010- |
KIA | Sorento 2.4 CVVT | [G4KE] | 01.2009- |
KIA | Sorento 2.4 CVVT | [G4KJ] | 01.2012- |
KIA | Sorento 2.4 CVVT 4WD | [G4KE] | 01.2009- |
KIA | Sorento 2.4 CVVT 4WD | [G4KJ] | 01.2012- |
KIA | Sorento 2.4 GDI | [G4KJ] | 01.2012- |
KIA | Sorento 2.4 GDI 4WD | [G4KJ] | 01.2012- |
Reference Information
20493461BN UD13972S 20479313BN FS14N1 CST15313AS 36100-2G250 S3162S STR80178 STV9090 MAV173130A 256104 STV9091 91-20-3559N 19090N LRS4154 849500 201-12109 36100-2G100 LRS04154 6032164 S-1513 6015313 25-5317 CST32164AS 36100-2g100 91-20-3559 MAV341640AVideo/Publications
19090N 201-12109 25-5317 256104 36100-2G100 849500 91-20-3559 91-20-3559N FS14N1 LRS04154 LRS4154 S-1513 STR80178 STV9090 STV9091 UD13972SAdd Your Number
