Associated Numbers
1195411 150.572.112 19224N 25-4346 255715V 36100-2B120 36100-2E120 36100-2E500 36100-2E550 6032144 88214541 91-20-3566 AEY2674 CST32144 CST32144AS CST32144ES CST32144GS CST32144OS CST32144RS DRS0816 DRS0816N LRS02674 S-6569 STA3626 UD13958SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 198 mm |
Mount Hole Center - Center (O.1) | 95 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 19.5 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Elantra 1.8 | 01.2011-12.2014 | |
HYUNDAI | Elantra 2.0 | 01.2014-12.2014 | |
HYUNDAI | i40 2.0 CWT | [G4NA] | 01.2012-12.2013 |
HYUNDAI | i40 2.0 GDi | [G4NC] | 01.2011-12.2013 |
KIA | Carens 2.0 GDi | [G4NC] | 01.2013-12.2013 |
KIA | Optima 2.0 CVVT Hybrid | [G4NE] | 01.2012-12.2013 |
KIA | Soul 2.0 | 01.2012-12.2013 |
Reference Information
255715V 88214541 S3132S CST32144AS STR0121 CST32144RS S-6569 36100-2E550 361002E120B DRS0816 STA3626 LRS02674 36100-2E500 19224N UD13958S LRS2674 CST32144 91-20-3566 6032144 AEY2674 36100-2E120 25-4346 1195411 150.572.112 36100-2B120 DRS0816N CST32144OS CST32144ES CST32144GSVideo/Publications
1195411 150.572.112 19224N 25-4346 255715V 36100-2B120 36100-2E120 36100-2E500 36100-2E550 6032144 88214541 91-20-3566 AEY2674 CST32144 CST32144AS CST32144ES CST32144GS CST32144OS CST32144RS DRS0816 DRS0816N LRS02674 LRS2674 S-6569 STA3626 UD13958SAdd Your Number
