Associated Numbers
0986023370 113796 12017 150.539.082 201349 201349V 20493801OE 22.1349 25-3358 33186N 36100-27050 36100-27510 6032108 8080283 8213009 88213009 8EA738239-001 9771 AET1349 CST32108 CST32108AS CST32108ES CST32108GS CST32108OS CST32108RS DRS0071 EAA-121125 GS027510-A JS1349 LRS02186 S3121 SS581 STR54131 TM000A31201 UD30024SSpecifications
Kilowatt | 1.7 kW |
Length (L.1) | 230 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | M10x1.75 mm |
Mount Hole Diameter (C.2) | M10x1.75 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 24 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Accent 1.5 CRDi | [D3-EA] | 01.2001-12.2005 |
HYUNDAI | Getz 1.5 CRDi | [D3-EA] | 01.2003-12.2005 |
HYUNDAI | Matrix 1.5 CRDi | [D3-EA] | 01.2001-12.2006 |
Reference Information
CST32108GS CST32108 000986023370 8EA738239-001 220398 150.539.082 STA0548R ANM12291X 6032108 20493801OE JS1349 986023370 RNL36100-27510 STR54131 36100-27050 003-C145 LRS02186 SS581 25-3358 201349V STRL219 AET1349 CST32108ES 5035236 GS027510-A 113796 8080283 CST32108AS STR0109 MTC145 CST32108RS STM1094 S3121 12017 CGB-27510 88213009 UD30024S TM000A31201 9771 DRS0071 8213009 201349 EAA-121125 MAV341080 331862 3C145 33186N LRS2186 22.1349 36100-27510 CST32108OS S12VA0212A2Video/Publications
003-C145 0986023370 113796 12017 150.539.082 201349 201349V 20493801OE 22.1349 25-3358 33186N 36100-27050 36100-27510 3C145 6032108 8080283 8213009 88213009 8EA738239-001 9771 AET1349 CGB-27510 CST32108 CST32108AS CST32108ES CST32108GS CST32108OS CST32108RS DRS0071 EAA-121125 GS027510-A JS1349 LRS02186 LRS2186 MAV341080 MTC145 RNL36100-27510 S3121 SS581 STR54131 STRL219 TM000A31201 UD30024S 220398Add Your Number
