Associated Numbers
0AM911023D 0AM911023DX 0AM911023Q 0AM911023QX 115376 12241 194156 199050 20479421OE 220646 25-4262 254556V 255125 255125V 300.583.122 30203N 3062 438227 458391 6015124 88214188 AEY2590 AM911023D AM911023DX AM911023Q AM911023QX CS1480 CST15124 CST15124AS CST15124ES CST15124GS CST15124OS CST15124RS DRS0882 DS1992 LRS02590 LRS2590 S3095 STR54136 STV3822 TS18ER20 TS18ER20B UD10753S VAL438227 VAL438252Specifications
Kilowatt | 1.8 kW |
Length (L.1) | 216 mm |
Mount Hole Center - Center (O.1) | 122 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
No./Teeth (Replaces) | 12 qty |
Pinion at Rest (B) | 62 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | A3 1.6 TDi | [CAYC] | 05.2009- |
AUDI | A3 1.6 TDi | [CAYC] | 05.2009-03.2013 |
AUDI | A3 1.6 TDi | [CAYC] | 05.2009-05.2013 |
AUDI | A3 1.6 TDi | [CAYC] | 05.2009-08.2012 |
SEAT | Altea 1.6 TDi | [CAYC] | 10.2009- |
SEAT | Altea 1.9 TDi | [BLS] | 04.2004- |
SEAT | Altea XL 1.9 TDi | [BKC] | 10.2006- |
SEAT | Altea XL 1.9 TDi | [BLS] | 10.2006- |
SEAT | Leon 1.6 TDi | [CAYC] | 02.2010- |
SEAT | Leon 1.9 TDi | [BLS] | 09.2005- |
SKODA | Fabia 1.6 TDi | [CAYA] | 04.2010- |
SKODA | Fabia 1.6 TDi | [CAYB] | 03.2010- |
SKODA | Fabia 1.6 TDi | [CAYC] | 03.2010- |
SKODA | Octavia 1.6 TDi | [CAYC] | 06.2009- |
SKODA | Octavia 1.6 TDi 4x4 | [CAYC] | 06.2009- |
SKODA | Roomster 1.6 TDi | [CAYB] | 03.2010- |
SKODA | Roomster 1.6 TDi | [CAYC] | 03.2010- |
VW | Caddy 1.6 TDi | [CAYD] | 08.2010- |
VW | Caddy 1.6 TDi | [CAYE] | 08.2010- |
VW | Golf Plus 1.6 TDi | [CAYC] | 03.2009- |
VW | Golf VI 1.6 TDi | [CAYB] | 12.2009- |
VW | Golf VI 1.6 TDi | [CAYB] | 12.2009-07.2013 |
VW | Golf VI 1.6 TDi | [CAYC] | 02.2009-11.2012 |
VW | Golf VI 1.6 TDi | [CAYC] | 07.2009- |
VW | Golf VI 1.6 TDi | [CAYC] | 07.2009-07.2013 |
VW | Golf V Plus 1.6 TDi | [CAYC] | 03.2009- |
VW | Polo 1.6 TDi | [CAYB] | 06.2009- |
VW | Touran 1.9 TDi | [BLS] | 11.2006-05.2010 |
Reference Information
CST15124GS 199050 0AM911023DX AM911023QX S12VA0349A2 300.583.122 88214188 CST15124AS TS18ER20 UD10753S 3062 CST15124ES 6015124 0AM911023QX 458391 30203N LRS2590 CST15124OS TS18ER20B STR54136 6.0572E+11 438227 CST15124 255125V 194156 220646 DS1992 AM911023D 5015857 S3095 12241 20479421OE 331028 AM911023Q LRS02590 AM911023DX 255125 0AM911023Q 115376 CS1480 STR00147 0AM911023D DRS0882 CST15124RS 25-4262 AEY2590 STRL876Video/Publications
0AM911023D 0AM911023DX 0AM911023Q 0AM911023QX 115376 12241 194156 199050 20479421OE 220646 25-4262 254556V 255125 255125V 300.583.122 30203N 3062 438227 458391 6015124 88214188 AEY2590 CS1480 CST15124 CST15124AS CST15124ES CST15124GS CST15124OS CST15124RS DRS0882 DS1992 LRS02590 LRS2590 S3095 STR54136 STRL876 STV3822 TS18ER20 TS18ER20B UD10753S VAL438227 VAL438252Add Your Number
