Associated Numbers
25-4258 254530 254530V 2H0911023A 2H0911023F 300.593.122 30302N-OE 458411 6015236 AEY2586 CST15236 CST15236AS CST15236ES CST15236GS CST15236OS CST15236RS DRS0677 LRS02586 STR54140 TS22ER12 TS22ER13
47-312 49312 16312
2012
Part number
TS22ER13
24482
0001153013
0001153014
0001153019
0001153020
DRS0677
254258
LRS2586
438243
458411
TS22ER12
02H903023F
02H911023A
02H911023AX
02H911023F
02H911023FX
02H911023H
Specifications
Kilowatt | 2.2 kW |
Length (L.1) | 223 mm |
Mount Hole Center - Center (O.1) | 109 mm |
Mount Hole Diameter (C.1) | M12x1.75 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 12 qty |
No./Teeth (Replaces) | 12 qty |
Pinion at Rest (B) | 12 mm |
Rotation | CW |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | Amarok 2.0 TDi | [CDBA] | 01.2010- |
VW | Amarok 2.0 TDi | [CDCA] | 01.2010- |
VW | Amarok 2.0 TDi | [CNEA] | 01.2010- |
VW | Amarok 2.0 TDi | [CNEA] | 01.2012- |
VW | Amarok 2.0 TDi | [CNFA] | 01.2010- |
VW | Amarok 2.0 TDi | [CNFB] | 01.2012- |
VW | Amarok 2.0 TDi | [CSHA] | 01.2010- |
VW | Amarok 2.0 TDi | [CSHA] | 01.2012- |
VW | Amarok 2.0 TDi 4-Motion | [CDBA] | 01.2010- |
VW | Amarok 2.0 TDi 4-Motion | [CDCA] | 01.2010- |
VW | Amarok 2.0 TDi 4-Motion | [CNEA] | 01.2010- |
VW | Amarok 2.0 TDi 4-Motion | [CNEA] | 01.2012- |
VW | Amarok 2.0 TDi 4-Motion | [CNFA] | 01.2010- |
VW | Amarok 2.0 TDi 4-Motion | [CNFB] | 01.2012- |
VW | Amarok 2.0 TDi 4-Motion | [CSHA] | 01.2010- |
VW | Amarok 2.0 TDi 4-Motion | [CSHA] | 01.2012- |
VW | Crafter 2.0 TDi | [CKTB] | 01.2011- |
VW | Crafter 2.0 TDi | [CKTC] | 01.2011- |
VW | Crafter 2.0 TDi | [CKUB] | 01.2011- |
VW | Crafter 2.0 TDi | [CKUB] | 01.2012- |
VW | Crafter 2.0 TDi | [CKUC] | 01.2011- |
VW | Crafter 2.0 TDi | [CSLB] | 01.2012- |
VW | Crafter 2.0 TDi 4-Motion | [CKUB] | 01.2012- |
VW | Crafter 2.0 TDi 4-Motion | [CSLB] | 01.2012- |
Reference Information
STR54140 EAA-153602 STV3212 AEY2586 HVW9099060026 201756 VALTS22ER12 116248 VALTS22ER13 2H0911023KX 9069060026 300.593.122.500 STR00314 25-4258 2H0911023FX 30302N SG1129 STRL747 A9069060026 CST15236GS 88214394 0001123041 20479632OE 30302N-OE 1123041 PRSL747 LRS02586 254530 TS22ER13 TS22ER12 2H0911023 2H0911023AX STR54168 3060 2H0911023K 460441 254530V 2H0911023F 2H0911023H 2H0911023A DRS0677 300.593.122.000 2H0911023HX 438243 458411 12216 STR0077 331029 220521 6015236.1 LRS2586Video/Publications
25-4258 254530 254530V 2H0911023A 2H0911023F 300.593.122 30302N-OE 458411 6015236 AEY2586 CST15236 CST15236AS CST15236ES CST15236GS CST15236OS CST15236RS DRS0677 LRS02586 LRS2586 STR54140 TS22ER12 TS22ER13 438243 220521Add Your Number
