Associated Numbers
0986017361 10882 111333 11675 20479951OE 20479951RC 22.0882 22.0882M 25-2209 25-3126 32366R 3644 42017361 455551 5002701 6015159 7700260710 7700759861 7700862838 7701352305 8017361 AEU0882 CS882 CST15159GS CST15159RS D6RA45 D6RA53 DRS3269 LRS01366 LRS01606 M1T74491 SS872 STR54041Specifications
Kilowatt | 1.1 kW |
Length (L.1) | 209 mm |
Mount Hole Center - Center (O.1) | 114 mm |
Mount Hole Center - Center (O.2) | 80 mm |
Mount Hole Center - Center (O.3) | 80 mm |
Mount Hole Diameter (C.1) | M8x1.25 mm |
Mount Hole Diameter (C.2) | M8x1.25 mm |
Mount Hole Diameter (C.3) | M8x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9. 10 qty |
Pinion at Rest (B) | 2 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | Alpine 3.0 Turbo | 01.1991-12.1995 | |
RENAULT | Espace 2.8 V6 | [Z7W717] | 04.1994-10.1996 |
RENAULT | Espace 3.0 | [Z7X775] | 11.1996-10.2002 |
RENAULT | Laguna 3.0 | [Z7X760] | 11.1993-03.2001 |
RENAULT | Laguna 3.0 | [Z7X765] | 11.1993-03.2001 |
RENAULT | Safrane 3.0 | [Z7X753] | 02.1993-06.1996 |
RENAULT | Safrane 3.0 Biturbo 4x4 | [Z7X726] | 02.1993-09.1996 |
RENAULT | Safrane 3.0 V6 | [Z7X721] | 05.1992-09.1996 |
RENAULT | Safrane 3.0 V6 | [Z7X722] | 05.1992-09.1996 |
RENAULT | Safrane 3.0 V6 | [Z7X723] | 05.1992-09.1996 |
RENAULT | Safrane 3.0 V6 4x4 | [Z7X721] | 12.1992-07.1996 |
RENAULT | Safrane 3.0 V6 4x4 | [Z7X722] | 12.1992-07.1996 |
RENAULT | Safrane 3.0 V6 4x4 | [Z7X723] | 12.1992-07.1996 |
Reference Information
LRS1366 STR54041 8017361 32366R 455551 AEU0882 111333 7701352305 32A6620100 7700260710 D6RA45 SS872 986017361 20479951RC LRS01366 STRS579 STR00216 M001T74491 CS882 25-3126 CST15159RS D6RA53 LRS1606 22.0882 LRS01606 DRS3269 7700751861 7700866785 CST15159GS 7700300501 S3073 7700759861 000986017361 JM001A74491 25-2209 20479951OE 22.0882M 6015159 5002701 1202162 MAV171590 7700862838 10882 3644 ANM15489X 11675 M1T74491 42017361Video/Publications
0986017361 10882 111333 11675 20479951OE 20479951RC 22.0882 22.0882M 25-2209 25-3126 32366R 3644 42017361 455551 5002701 6015159 7700260710 7700759861 7700862838 7701352305 8017361 AEU0882 CS882 CST15159GS CST15159RS D6RA45 D6RA53 DRS3269 LRS01366 LRS01606 LRS1366 LRS1606 M1T74491 MAV171590 SS872 STR54041 STRS579Add Your Number
