S3070 - Brand new AS-PL Starter motor

Specifications

Kilowatt	1.8 kW
Length (L.1)	219 mm
Mount Hole Center - Center (O.1)	102 mm
Mount Hole Diameter (C.1)	9.5 mm
Mount Hole Diameter (C.2)	M8x1.25 mm
No./Mount holes	2 qty
No./Mount holes with thread	1 qty
No./Teeth	10 qty
No./Teeth (Replaces)	10 qty
Pinion at Rest (B)	24 mm
Rotation	CW
Spigot Diameter (A)	64 mm
Unit Type	VALEO
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
CHEVROLET	Aveo 1.3 D	[LDV]	07.2011-12.2015
CHEVROLET	Aveo 1.3 D	[LSF]	07.2011-12.2015
OPEL	Agila 1.3 CDTi	[Z13DT]	08.2003-12.2007
OPEL	Astra 1.3 CDTi	[A13DTE]	05.2013-10.2015
OPEL	Astra 1.3 CDTi	[A13DTE]	06.2012-10.2015
OPEL	Astra 1.3 CDTi	[A13DTE]	10.2012-10.2015
OPEL	Astra 1.3 CDTi	[A13DTE]	12.2009-10.2015
OPEL	Astra 1.3 CDTi	[Z13DTH]	02.2007-10.2010
OPEL	Astra 1.3 CDTi	[Z13DTH]	08.2005-10.2010
OPEL	Astra 1.3 CDTi Sports Tourer	[A13DTE]	10.2010-10.2014
OPEL	Astra GTC 1.3 CDTi	[Z13DTH]	04.2005-10.2010
OPEL	Astra H 1.3 CDTi	[Z13DTH]	08.2005-09.2010
OPEL	Astra H 1.3 CDTi GTC	[Z13DTH]	08.2005-
OPEL	Astra J 1.3 CDTi	[A13DTE]	01.2010-
OPEL	Astra J 1.3 CDTi	[A13DTF]	01.2010-
OPEL	Combo 1.3 CDTi 16V	[Z13DT]	08.2005-
OPEL	Combo 1.3 CDTi 16V	[Z13DTJ]	10.2005-12.2012
OPEL	Combo Tour 1.3 CDTi 16V	[Y13DT]	06.2004-01.2011
OPEL	Combo Tour 1.3 CDTi 16V	[Z13DT]	06.2004-01.2011
OPEL	Combo Tour 1.3 CDTi 16V	[Z13DTJ]	10.2005-12.2011
OPEL	Corsa 1.3 CDTi	[A13DTC]	07.2006-08.2014
OPEL	Corsa 1.3 CDTi	[A13DTE]	06.2009-08.2014
OPEL	Corsa 1.3 CDTi	[A13DTE]	11.2009-08.2014
OPEL	Corsa 1.3 CDTi	[A13DTR]	06.2009-08.2014
OPEL	Corsa 1.3 CDTi	[A13DTR]	11.2009-08.2014
OPEL	Corsa 1.3 CDTi	[Y13DT]	06.2003-12.2009
OPEL	Corsa 1.3 CDTi	[Z13DT]	06.2003-12.2009
OPEL	Corsa 1.3 CDTi	[Z13DTE]	06.2009-08.2014
OPEL	Corsa 1.3 CDTi	[Z13DTE]	11.2009-08.2014
OPEL	Corsa 1.3 CDTi	[Z13DTH]	07.2006-06.2010
OPEL	Corsa 1.3 CDTi	[Z13DTH]	07.2006-06.2011
OPEL	Corsa 1.3 CDTi	[Z13DTJ]	07.2006-08.2014
OPEL	Corsa 1.3 CDTi 16V	[Z13DT]	07.2005-06.2006
OPEL	Corsa D 1.3 CDTi	[A13DTC]	07.2006-
OPEL	Corsa D 1.3 CDTi	[A13DTR]	06.2010-
OPEL	Corsa D 1.3 CDTi	[Z13DTH]	07.2006-
OPEL	Corsa D 1.3 CDTi	[Z13DTJ]	07.2006-
OPEL	Meriva 1.3 CDTi	[A13DTC]	06.2010-10.2013
OPEL	Meriva 1.3 CDTi	[A13DTE]	06.2010-11.2014
OPEL	Meriva 1.3 CDTi	[Y13DT]	04.2005-05.2010
OPEL	Meriva 1.3 CDTi	[Z13DT]	04.2005-05.2010
OPEL	Meriva 1.3 CDTi	[Z13DTJ]	09.2003-05.2010

Reference Information

8214249 TS18E331 196039 6202071 458351 RNLTS18E33 1638119980 WG2196670 S12VA0084A SS740 10439606 2131377 000986022730 CST15221GS A22730 H5015081 6202083 STR0096 55217672 438212 PRSL154 TS18E33 S-54088 10015221AV 9.44281E+11 CS1511 2176 20479122BN 3142 TT15192 6202099 130.547.102.006 6202095 8080234 93169309 3110764 3110765 S3070 LRS2348 12140 SX OP9041 22.1511M 328065102 201102 11022730 STX200253 SG0560 130.547.102.000 S12VA0084 STM1186 CST15221AS S12VA0084A2 130.547.102.505 QRS2075 EZ0092 220432 114029 AEY2348 93169458 130.547.102.500 SVA221 DSN3047 55564491 5015081 10015221OV 6015221 1265030 93190320 ST01548 55221292 8550504857 460477 254307V 93186246 ANM12343X 93189232 DRS0123 WG2012983 WG2012982 STR54088 LRS02348 SVA221A 011-001-000622R AC-CBS1511 R1530109 20479122OE R1530103 4736003 TT15192PRO EAA-121519 60105011 986022730 R1540025 6015221.1 140ST21 33345N 22.1511 93191079 254307 8EA011612-601 106473 6202105 1202209 130.547.102 63721511010 V40-12-50001 ANM12343 130.547.102.280 STRL154 BST2354 220432A 88214249 STX200253R 25-4020

Video/Publications

0986022730 114029 12140 130.547.102 20479122BN 20479122OE 22.1511 22.1511M 25-4020 254307V 33345N 55221292 55564491 60105011 6015221 6202105 8214249 93191079 AEY2348 CS1511 CST15221AS CST15221GS DRS0123 EAA-121519 LRS02348 LRS2348 RNLTS18E33 S3070 SS740 STR54088 STRL154 SX 2176 TS18E331 220432
