Associated Numbers
0001107067 0986018400 0986018581 101060 113605 11803 20479341BN 20479341OE 20510174 22.1060 25-2195 30173N 30808465 3860 432670 455693 6015143 7700865985 7701499615 8018400 8111635 8212378 8602102 88212378 8EA012527-211 8EA737376-001 AES1274 CS1060 CST15143 CST15143AS CST15143ES CST15143GS CST15143OS CST15143RS D6RA63 DRS3625 EAA-121344 LRT00174 ND164 SS449 STR54018Specifications
Kilowatt | 1.1 kW |
Length (L.1) | 209 mm |
Mount Hole Center - Center (O.1) | 54 mm |
Mount Hole Center - Center (O.2) | 98 mm |
Mount Hole Center - Center (O.3) | 63 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | -1.5 mm |
Rotation | CW |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | Laguna 2.0 16V | [N7Q700] | 06.1995-03.2001 |
RENAULT | Laguna 2.0 16V | [N7Q704] | 06.1995-03.2001 |
VOLVO | S40 1.6 | [B4164S] | 09.1995-08.1999 |
VOLVO | S40 1.6 | [B4164S2] | 08.1999-01.2004 |
VOLVO | S40 1.8 | [B4184S] | 07.1995-08.1999 |
VOLVO | S40 1.8 | [B4184S2] | 03.1999-12.2003 |
VOLVO | S40 1.8 | [B4184S3] | 08.1999-01.2004 |
VOLVO | S40 1.8 | [B4184S9] | 03.1999-01.2004 |
VOLVO | S40 1.9 T4 | [B4194T] | 05.1997-07.1999 |
VOLVO | S40 1.9 T4 | [B4194T2] | 08.1999-07.2000 |
VOLVO | S40 2.0 | [B4204S] | 07.1995-08.1999 |
VOLVO | S40 2.0 16V | [B4204S] | 07.1995-08.1999 |
VOLVO | S40 2.0 16V | [B4204S2] | 07.1999-12.2003 |
VOLVO | S40 2.0 Turbo | [B4204T] | 10.1997-07.2000 |
VOLVO | S40 2.0 Turbo T4 | [B4204T5] | 07.2000-12.2003 |
VOLVO | V40 1.6 | [B4164S] | 12.1995-08.1999 |
VOLVO | V40 1.6 | [B4164S2] | 03.1999-04.2004 |
VOLVO | V40 1.8 | [B4184S] | 07.1995-08.1999 |
VOLVO | V40 1.8 | [B4184S2] | 03.1999-04.2004 |
VOLVO | V40 1.8 | [B4184S3] | 08.1999-04.2004 |
VOLVO | V40 1.8 | [B4184S9] | 03.1999-04.2004 |
VOLVO | V40 1.9 T4 | [B4194T] | 05.1997-07.1999 |
VOLVO | V40 2.0 | [B4204S] | 07.1995-08.1999 |
VOLVO | V40 2.0 16V | [B4204S2] | 07.1995-04.2004 |
VOLVO | V40 2.0 Turbo | [B4204T3] | 06.2001-04.2004 |
VOLVO | V40 2.0 Turbo 16V | [B4204T] | 04.1998-07.1999 |
VOLVO | V40 2.0 Turbo T4 | [B4204T5] | 07.2000-04.2004 |
Reference Information
7700865985 CST15143AS 000986018581 30808465 0001107067 1107067 S12BH0810A2 STRS097 331212 CST15143ES 6015143 7701499616 7701499615 88212378 STR54018 25-2195 8212378 20479341OE 8018400 20510174 20479341BN 220465 986018581 LRT00174 8EA012527-211 S12VA0151A2 EAA-121344 113605 AES1274 CST15143RS D6RA63 30821273 30173N 432670 000986018400 455693 3860 CST15143GS 3082127 8602102 8602066 8602067 36050274 11803 7700871055 ND164 CST15143OS DRS3625 8111635 MAV4710 CST15143 STA0348R 101060 STR0038 22.106 SS449 8EA737376-001 S3030 986018400 86020674 CS1060 3080847 7700862838 3080846 ANM15845XVideo/Publications
0001107067 0986018400 0986018581 101060 113605 11803 20479341BN 20479341OE 20510174 22.1060 25-2195 30173N 30808465 3860 432670 455693 6015143 7700865985 7701499615 8018400 8111635 8212378 8602102 88212378 8EA012527-211 8EA737376-001 AES1274 CS1060 CST15143 CST15143AS CST15143ES CST15143GS CST15143OS CST15143RS D6RA63 DRS3625 EAA-121344 LRT00174 MAV4710 ND164 S3030 SS449 STR54018 STRS097 220465Add Your Number
