Associated Numbers
0986016730 114199 11952 160.531.082 201016 201079 201307 201307V 220495 23300-1F770 23300-1F771 23300-1F772 23300-1F77A 23300-1F77B 23300-1F77C 25-2247 33080N 33080R 438136 455985 6045110 88213076 8EA011610-781 8EA738139-001 943213071010 943241027010 944280167300 9571 AET1307 CST45110 CST45110AS CST45110ES CST45110GS CST45110OS CST45110RS D7E30 D7E32 D7E40 D7E40B D7E42 DRS3945 DRS6730 DS5055 DS7840 EAA-121137 EAA-121347 GS438136-A J5211092 JS1307 LRS02080 M002T42881 M2T42881 MRS16730 MSR1027 MSRC1307 STV1307 TS8E3Specifications
Kilowatt | 0.7 kW |
Length (L.1) | 169 mm |
Mount Hole Center - Center (O.1) | 106 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 8 qty |
Pinion at Rest (B) | 10 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Micra 1.0 16V | [CG10DE] | 01.2003-06.2010 |
NISSAN | Micra 1.0 i 16V | [CG10DE] | 09.2000-02.2003 |
NISSAN | Micra 1.2 16V | [CG12DE] | 01.2003-06.2010 |
NISSAN | Micra 1.2 16V | [CR12DE] | 01.2003-06.2010 |
NISSAN | Micra 1.2 LPG | [CR12DE] | 06.2005-06.2010 |
NISSAN | Micra 1.4 16V | [CR14DE] | 08.2005- |
NISSAN | Micra 1.4 i 16V | [CGA3DE] | 09.2000-02.2003 |
NISSAN | Note 1.4 | [CR14DE] | 03.2006- |
Reference Information
88213076 SS477 S12VA0132A2 MTD211 233001F772B 114199 MAV471100 M2T42881 6045110 455985 TS8E3 DRS6730 EAA-121347 MAV471060 3D211 STR0019 LRS2080 20417011RE DS5055 M0T84585AM 9.43213E+11 M002T42881 23300-AX000 2330099B10 160.531.082.009 220495 160.531.082.008 233001F715 SS499 RNLD7E32 160.531.082.000 20417011BN 233001F710 S12VA0132 233009W200 6045110.4 2330099B16 6045110.1 23300-99A10 000986016730 33080R 9.43241E+11 33080N 003-D211 MSR1027 2330041B71 23300-AX00A GS438136-A 23300-AX002 23300-1F772B 8EA011610-781 160.531.082.505 EAA-121137 23300-94851 160.531.082.500 LRS02080 M0T84585 MSRC1307 DS7840 23300-99B10 JS1307 23300-1F710 23300-1F7R1 8EA738139-001 9.4428E+11 AET1307 CST45110AS CGB-26730 11952 438136 23300AX010 D7E32 23300AX01A DRS3945 STRL046 986016730 D7E30 20417011OE 23300AX000 D7E40B STM591 201307V CST45110OS MRS16730 D7E42 201307 9571 335866 23300-1F772 23300-1F771 23300-1F770 23300AX002 STV1307 M000T84585 STRS743 D7E40 25-2247 ANM12901 B33001F77C 23300-1F77C 23300-1F77B 23300-1F77A CST45110GS 23300AX00A J5211092 23300AX00BVideo/Publications
003-D211 0986016730 113644 114199 11952 160.531.082 201016 201079 201307 201307V 220495 23300-1F770 23300-1F771 23300-1F772 23300-1F77A 23300-1F77B 23300-1F77C 25-2247 33080N 33080R 3D211 438136 455985 6045110 88213076 8EA011610-781 8EA738139-001 943213071010 943241027010 944280167300 9571 AET1307 CGB-26730 CST45110 CST45110AS CST45110ES CST45110GS CST45110OS CST45110RS D7E30 D7E32 D7E40 D7E40B D7E42 DRS3945 DRS6730 DS5055 DS7840 EAA-121137 EAA-121347 GS438136-A J5211092 JS1307 LRS02080 LRS2080 M002T42881 M2T42881 MAV471060 MAV471100 MRS16730 MSR1027 MSRC1307 MTD211 STRL046 STRS743 STV1307 TS8E3Add Your Number
