Associated Numbers
0986021051 101174 101174V 11.139.449 112218 11871 20479011 20510237 220023 25-2387 3001 31250N 32565N 32565R 42455876 438054 455876 570.519.083 6.0041.9 6015110 726024 72735645 7700104674 7711134530 88212720 8EA011610-061 8EA737725-001 943223239010 944280800620 AES2237 AZE1244 CS1174 CST15110 CST15110AS CST15110ES CST15110GS CST15110OS CST15110RS D7E22 D7E6 DRS3624 DRS3776 DS4734 DS4886 EAA-121271 GS438054-A GS438054V-R IS9441 LRT00237 MRS80062 MS17 MSR277 NES2237 RAS34735 S3008 SG0169 STM1174 STR54052 STV1174 STV8174 STV9174 TS10E5 VAL438054Specifications
Kilowatt | 1 kW |
Length (L.1) | 169 mm |
Mount Hole Center - Center (O.1) | 65 mm |
Mount Hole Center - Center (O.2) | 105 mm |
Mount Hole Center - Center (O.3) | 73 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 8 qty |
No./Teeth (Replaces) | 8, 9 qty |
Pinion at Rest (B) | -3 mm |
Rotation | CW |
Spigot Diameter (A) | 65 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
RENAULT | Clio 1.4 16V | [K4J710] | 08.2000- |
RENAULT | Clio 1.4 16V | [K4J711] | 08.2000- |
RENAULT | Clio 1.4 16V | [K4J712] | 08.2000- |
RENAULT | Clio 1.4 16V | [K4J713] | 08.2000- |
RENAULT | Clio 1.6 16V | [K4M708] | 09.1998- |
RENAULT | Clio 1.6 16V | [K4M740] | 09.1998- |
RENAULT | Clio 1.6 16V | [K4M742] | 09.1998- |
RENAULT | Clio 1.6 16V | [K4M743] | 09.1998- |
RENAULT | Clio 1.6 16V | [K4M744] | 09.1998- |
RENAULT | Clio 1.6 16V | [K4M745] | 09.1998- |
RENAULT | Clio 1.6 16V | [K4M748] | 09.1998- |
RENAULT | Clio 1.6 Flex | 05.2000-12.2006 | |
RENAULT | Clio 1.6 Hi-Flex | [K4M748] | 01.2005-02.2010 |
RENAULT | Kangoo 1.6 16V | [K4M750] | 06.2001- |
RENAULT | Kangoo 1.6 16V | [K4M752] | 06.2001- |
RENAULT | Kangoo 1.6 16V | [K4M753] | 06.2001- |
RENAULT | Kangoo 1.6 16V 4x4 | [K4M750] | 10.2001- |
RENAULT | Kangoo 1.6 16V 4x4 | [K4M752] | 10.2001- |
RENAULT | Kangoo 1.6 16V 4x4 | [K4M753] | 10.2001- |
RENAULT | Kangoo 1.6 16V Express | [K4M752] | 10.2001- |
RENAULT | Kangoo 1.6 16V Express 4x4 | [K4M750] | 10.2001- |
RENAULT | Kangoo 1.6 16V Express 4x4 | [K4M752] | 10.2001- |
RENAULT | Kangoo 1.6 16V Express 4x4 | [K4M753] | 10.2001- |
RENAULT | Laguna 1.6 16V | [K4M710] | 03.2001- |
RENAULT | Laguna 1.6 16V | [K4M720] | 11.1997-03.2001 |
RENAULT | Laguna 1.6 16V | [K4M724] | 11.1997-03.2001 |
RENAULT | Megane 1.4 16V | [K4J714] | 03.1999- |
RENAULT | Megane 1.4 16V | [K4J714] | 03.1999-08.2003 |
RENAULT | Megane 1.4 16V | [K4J730] | 11.2002- |
RENAULT | Megane 1.4 16V | [K4J740] | 11.2002- |
RENAULT | Megane 1.4 16V | [K4J750] | 03.1999- |
RENAULT | Megane 1.4 16V | [K4J750] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V | [K4M700] | 03.1999- |
RENAULT | Megane 1.6 16V | [K4M700] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V | [K4M701] | 03.1999- |
RENAULT | Megane 1.6 16V | [K4M701] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V | [K4M704] | 03.1999- |
RENAULT | Megane 1.6 16V | [K4M704] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V | [K4M708] | 03.1999- |
RENAULT | Megane 1.6 16V | [K4M708] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V | [K4M760] | 11.2002- |
RENAULT | Megane 1.6 E | [K7M702] | 01.1997-09.1999 |
RENAULT | Scenic 1.4 16V | [K4J714] | 09.1999-08.2003 |
RENAULT | Scenic 1.4 16V | [K4J750] | 09.1999-08.2003 |
RENAULT | Scenic 1.6 | [K4M700] | 09.1999-09.2003 |
RENAULT | Scenic 1.6 | [K4M706] | 09.1999-09.2003 |
RENAULT | Scenic 1.6 | [K4M707] | 09.1999-09.2003 |
RENAULT | Scenic 1.6 | [K4M708] | 03.2001-08.2003 |
RENAULT | Scenic 1.6 | [K4M709] | 03.2001-08.2003 |
RENAULT | Scenic 1.6 | [K4M776] | 09.1999-09.2003 |
RENAULT | Scenic 1.6 16V | [K4M700] | 09.1999-08.2003 |
RENAULT | Scenic 1.6 16V | [K4M701] | 09.1999-08.2003 |
RENAULT | Scenic 1.6 16V | [K4M704] | 09.1999-08.2003 |
RENAULT | Scenic 1.6 16V | [K4M708] | 09.1999-08.2003 |
RENAULT | Scenic 1.6 i 16V | [K4M761] | 06.2003- |
RENAULT | Thalia 1.4 16V | [K4J712] | 08.2000- |
RENAULT | Thalia 1.6 16V | [K4M734] | 09.2008- |
RENAULT | Thalia 1.6 16V | [K4M740] | 04.2002- |
Reference Information
STR79683 STA0374R 570.519.083.500 3001 7711135335 8EA011610-061 S12VA0101 570.519.083.505 AES2237 STR0008 CS1174 LRT237 8200049826 32565N 455983 20510237 MRS80062 104674 6025008446 331326 D7E22 S12VA0101A2 201168 CST15110AS 31250N 201011 25-2387 570.519.083.001 42455876 6015110 105119F 88212720 MSR277 11871 11.139.449 IS9441 000986021051 EAA-121271 72735645 101174 6015110.1 9.44281E+11 233001105R 570.519.083.008 STRL081 8253873 S3008 8253504 570.519.083.770 ANM15844X 963781368 D7E6 9.43223E+11 STV1174 112218 AZE1244 23300-00QAA LRT00237 CST15110GS 20479011BN 8200082782 7700104674 MS17 STM954 7711134530 STM714 20479011OE 101174R 101174V 7700105119 PRSL081 2330000QAA 986021051 455876Video/Publications
0986021051 101174 101174V 11.139.449 112218 11871 20479011 20510237 220023 25-2387 3001 31250N 32565N 32565R 42455876 438054 570.519.083 6.0041.9 6015110 726024 72735645 7700104674 7711134530 8200082782 88212720 8EA011610-061 8EA737725-001 943223239010 944280800620 AES2237 AZE1244 CGB-23776 CS1174 CST15110 CST15110AS CST15110ES CST15110GS CST15110OS CST15110RS D7E22 D7E6 DRS3624 DRS3776 DS4734 DS4886 EAA-121271 GS438054-A GS438054V-R IS9441 LRT00237 MAV171100 MAV4740 MRS80062 MS 17 MS17 MSR277 NES2237 RAS34735 RNL2105 RNLD7E19 S3008 SG0169 STM1174 STR54052 STRL081 STV1174 STV8174 STV9174 TS10E5 VAL438054 220441Add Your Number
