Associated Numbers
104-10245 114401 118400-77010 18440N 18440R 240-14117 25-4337 254271 630.516.112 71-25-18440 8184 88214741 AM879072 LRS02665 S114-821 S114-821A STH9072 STR72050 UD20563SSpecifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 194 mm |
| Mount Hole Center - Center (O.1) | 104 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 24.5 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JOHN DEERE | F735 | [2V78] | 01.1998-12.2003 |
| JOHN DEERE | GX355 | [2V78] | 01.2002-12.2005 |
Reference Information
AM879072 18440R 88214741 71-25-18440 STR72050 114401 254271 18440N 336431 UD20563S 25-4337 20445282BN LRS2665 630.516.112 6020282 STR3268 S114-821 8184 240-14117 LRS02665 118400-77010 104-10245 STH9072 CST20282AS MAV222820A S114-821AVideo/Publications
104-10245 114401 118400-77010 18440N 18440R 240-14117 25-4337 254271 630.516.112 71-25-18440 8184 88214741 AM879072 LRS02665 LRS2665 S114-821 S114-821A STH9072 STR72050 UD20563SAdd Your Number
