Associated Numbers
S114-832 UD12434SSpecifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 186 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 22.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 88.5 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | Engine | [4JE1] |
Reference Information
S114-832 UD12434SVideo/Publications
S114-832 UD12434SAdd Your Number
