Associated Numbers
129940-77010 19708 19708N 20445622BN 20445622OE 254757 254757M 6020226 CST20226AS CST20226GS S-80439 S14-102 S2049 STR72120 UD02161SSpecifications
| Kilowatt | 3 kW |
| Length (L.1) | 241 mm |
| Mount Hole Center - Center (O.1) | 120 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| No./Teeth (Replaces) | 9 qty |
| Pinion at Rest (B) | 21 mm |
| Rotation | CW |
| Spigot Diameter (A) | 95 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| GEHL | 4640E 3.3 | [4TNV98] | 01.2011-12.2021 |
| GEHL | 5640E | [4TNV98T] | 01.2006-12.2010 |
| GEHL | 6640E | [4TNV98T] | 01.2006-12.2010 |
| GEHL | CL65 | [4TNV98] | 01.2005-12.2010 |
| GEHL | CL75 | [4TNV98] | 01.2005-12.2010 |
| JCB | G13QX 3.3 | [4TNV98] | |
| JCB | G13QX 3.3 | [4TNV98T] | |
| JCB | G13X 3.3 | [4TNV98] | |
| JCB | G13X 3.3 | [4TNV98T] | |
| JCB | G17QX 3.3 | [4TNV98] | |
| JCB | G17QX 3.3 | [4TNV98T] | |
| JCB | G17X 3.3 | [4TNV98] | |
| JCB | G17X 3.3 | [4TNV98T] | |
| JCB | G20RX 3.3 | [4TNV98] | |
| JCB | G20RX 3.3 | [4TNV98T] | |
| JCB | G22QX 3.3 | [4TNV98] | |
| JCB | G22QX 3.3 | [4TNV98T] | |
| JCB | G22X 3.3 | [4TNV98] | |
| JCB | G22X 3.3 | [4TNV98T] | |
| JCB | G30RX 3.3 | [4TNV98] | |
| JCB | G30RX 3.3 | [4TNV98T] | |
| JCB | G33QX 3.3 | [4TNV98] | |
| JCB | G33QX 3.3 | [4TNV98T] | |
| JCB | G33X 3.3 | [4TNV98] | |
| JCB | G33X 3.3 | [4TNV98T] | |
| JCB | G34QX 3.3 | [4TNV98] | |
| JCB | G34QX 3.3 | [4TNV98T] | |
| JCB | G34X 3.3 | [4TNV98] | |
| JCB | G34X 3.3 | [4TNV98T] | |
| JCB | G40RX 3.3 | [4TNV98] | |
| JCB | G40RX 3.3 | [4TNV98T] | |
| JCB | G45QX 3.3 | [4TNV98] | |
| JCB | G45QX 3.3 | [4TNV98T] | |
| JCB | G45X 3.3 | [4TNV98] | |
| JCB | G45X 3.3 | [4TNV98T] | |
| JCB | G46QX 3.3 | [4TNV98] | |
| JCB | G46QX 3.3 | [4TNV98T] | |
| JCB | G46X 3.3 | [4TNV98] | |
| JCB | G46X 3.3 | [4TNV98T] | |
| JCB | G8QX 3.3 | [4TNV98] | |
| JCB | G8QX 3.3 | [4TNV98T] | |
| JCB | G8X 3.3 | [4TNV98] | |
| JCB | G8X 3.3 | [4TNV98T] | |
| JOHN DEERE | 204K 3.3 | [4TNV98] | 01.2013-12.2018 |
| JOHN DEERE | 204L 3.3 | [4TNV98] | 01.2017-12.2017 |
| JOHN DEERE | 244K 3.3 | [4TNV98] | 01.2014-12.2018 |
| JOHN DEERE | 244K-II 3.3 | [4TNV98] | 01.2016-12.2018 |
| JOHN DEERE | 244L 3.3 | [4TNV98] | 01.2018-12.2018 |
| JOHN DEERE | 304K 3.3 | [4TNV98] | 01.2013-12.2018 |
| JOHN DEERE | 304L 3.3 | [4TNV98] | 01.2017-12.2018 |
| JOHN DEERE | 310L EP 3.3 | [4TNV98] | 01.2014-12.2018 |
| JOHN DEERE | 318E 3.3 | [4TNV98] | 01.2013-12.2018 |
| JOHN DEERE | 319E 3.3 | [4TNV98] | 01.2013-12.2018 |
| JOHN DEERE | 320E 3.3 | [4TNV98] | 01.2013-12.2018 |
| JOHN DEERE | 320G 3.3 | [4TNV98] | 01.2018-12.2019 |
| JOHN DEERE | 323E 3.3 | [4TNV98] | 01.2013-12.2018 |
| JOHN DEERE | 324E 3.3 | [4TNV98] | 01.2016-12.2018 |
| JOHN DEERE | 324G 3.3 | [4TNV98] | 01.2018-12.2019 |
| JOHN DEERE | 324K 3.3 | [4TNV98] | 01.2014-12.2018 |
| JOHN DEERE | 324L 3.3 | [4TNV98] | 01.2018-12.2018 |
| JOHN DEERE | 325G 3.3 | [4TNV98] | 01.2018-12.2019 |
| JOHN DEERE | 326E 3.3 | [4TNV98] | 01.2013-12.2018 |
| JOHN DEERE | 328E 3.0 | [4TNV94] | 01.2013-12.2018 |
| JOHN DEERE | 329E 3.0 | [4TNV94] | 01.2013-12.2018 |
| JOHN DEERE | 330G 3.0 | [4TNV94] | 01.2016-12.2018 |
| JOHN DEERE | 331G 3.0 | [4TNV94] | 01.2016-12.2018 |
| JOHN DEERE | 332E 3.0 | [4TNV94] | 01.2013-12.2018 |
| JOHN DEERE | 332G 3.0 | [4TNV94] | 01.2016-12.2018 |
| JOHN DEERE | 333E 3.0 | [4TNV94] | 01.2013-12.2018 |
| JOHN DEERE | 333G 3.0 | [4TNV94] | 01.2016-12.2018 |
| JOHN DEERE | 60D 3.3 | [4TNV98] | 01.2008-12.2014 |
| JOHN DEERE | 60G 3.3 | [4TNV98] | 01.2013-12.2018 |
| KOMATSU | PC80MR-3 3.3 | [4D98E] | 01.2008-12.2019 |
| MUSTANG | 2066 | [4TNV98T] | 01.2005-12.2010 |
| MUSTANG | 2066 3.3 | [4TNV98T] | 01.2004-12.2010 |
| MUSTANG | 2076 | [4TNV98T] | 01.2005-12.2010 |
| MUSTANG | 2076 3.3 | [4TNV98T] | 01.2005-12.2014 |
| MUSTANG | 2086 | [4TNV98T] | 01.2005-12.2010 |
| MUSTANG | 2086 3.3 | [4TNV98T] | 01.2005-12.2014 |
| MUSTANG | MTL316 | [4TNV98] | 01.2009-12.2010 |
| TAKEUCHI | TB175 3.3 | [4TNV98] | 01.2007-12.2011 |
| TAKEUCHI | TB180FR 3.3 | [4TNV98] | 01.2008-12.2014 |
| TAKEUCHI | TL230 3.3 | [4TNV98] | 01.2008-12.2014 |
| TAKEUCHI | TL240 3.3 | [4TNV98] | 01.2008-12.2014 |
| YANMAR | Engine | [4TNV106] | 01.2004-12.2007 |
| YANMAR | Engine | [4TNV106-GGE] | 01.2000-12.2007 |
| YANMAR | Engine | [4TNV98] | 01.2004-12.2007 |
Reference Information
UD21306S STR3238 CST20226GS 14522114 S14-102A S14-102B HITHST14102B 19708N STRS294 335533 STH6221 19708 STR72120 LRS02678 104-10147N 6020226.1 300516-00051 980.523.092.080 11957877010 8180 6020226 PRSS294 S-80439 104-10147 STM7221 980.523.092.088 S2049 88214783 STH0221 LRS2678 20445622BN CST20226AS 129940-77010 DRS0957 S14102C UD02161S 91-25-1235 20445622OE 980.523.092.270 VOE15065343 25-4350 HST14102C HST14102B S14-102 114874 K9006124 CGB-94102 129940-77012 129940-77011 15065343 254757M 254757 254757HVideo/Publications
129940-77010 19708 19708N 20445622BN 20445622OE 254757 254757M 6020226 CST20226AS CST20226GS S-80439 S14-102 S2049 STR72120 UD02161S K9006124 300516-00051Add Your Number
