Associated Numbers
104-10137 112676 129900-77010 129900-77040 18491N 20445441BN 20445441OE 25-3064 254136 254136V 255892V 6020144 8919 980.510.092 CST20144 CST20144AS CST20144ES CST20144GS CST20144OS CST20144RS EAA-121182 HITS13-204 LRS01565 RNLS13-204 S-80646 S13-204 S13-205 S13-205G S13-404 S2041 STH2676 STR72069 UD00316S UD02352S UD15221S 16-337Specifications
Kilowatt | 2.3 kW |
Length (L.1) | 230 mm |
Mount Hole Center - Center (O.1) | 120 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | HITACHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KOMATSU | D21A | [4D95S] | 01.2001-12.2006 |
KOMATSU | WA70A-1 | [4D98E] | 01.1992-12.1998 |
YANMAR | 8002 | [4TNE98-NSR] | 01.2003-12.2007 |
YANMAR | SE50-3 | [4TNE94] | 01.1992-12.1998 |
Reference Information
STR3114 S13-404 CST20144ES 254136V 255892V UD00316S LRS1565 STH2676 MAV221440 S13-205G 112676 AT211995 EAA-121182 S2041 6020144 580062748 000F042004030 1599845 254136 4TNE98 S13-204 UD02352S CGB-23069 S13-205 F042004030 F042S04030 980.510.092.310 CST20144OS CST20144 CST20144GS 136958 129900-77040 LRS01565 HST13204 RNLS13-204 2506958 104-10137 S-80646 25-3064 STR72069 18491N 980.510.092.360 20445441OE 980.510.092.089 CST20144RS 980.510.092.088 980.510.092.006 336247 20445441BN 8919 129900-77010 129900-77011 CST20144AS UD15221S 980.510.092.080 HITS13-204Video/Publications
104-10137 112676 129900-77010 129900-77040 18491N 20445441BN 20445441OE 25-3064 254136 254136V 255892V 6020144 8919 980.510.092 CGB-23069 CST20144 CST20144AS CST20144ES CST20144GS CST20144OS CST20144RS EAA-121182 HITS13-204 LRS01565 LRS1565 MAV221440 RNLS13-204 S-80646 S13-205 S13-205G S13-404 S2041 STH2676 STR72069 UD00316S UD02352S UD15221SAdd Your Number
