Associated Numbers
111763 11894 160.579.092 17196N 201104 20417101BN 22.1104 23300-88G00 23300-88G01 25-2216 458631 6045101 88213133 8EA737508-001 AEY1370 CST45101 CST45101AS CST45101ES CST45101GS CST45101OS CST45101RS DRS3849 JS1104 LRS01370 S114-528 S114-528A S2018 STR-3024 STR72095 snj409 70-6200 HXS060 HXS077
Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 214 mm |
Mount Hole Center - Center (O.1) | 109 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 14.5 mm |
Rotation | CW |
Spigot Diameter (A) | 82 mm |
Unit Type | HITACHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | King Cab 3.0 i V6 4WD | (D21)[VG30E] | 09.1990-02.1998 |
NISSAN | TeRano 3.0 i | (WD21)[VG30E] | 08.1990-12.1995 |
Alternatives >>>
S2032 - Has 2 pin plug for exciter terminal
Reference Information
AEY1370 ANM16069X JS1104 88213133 23300-88G01 23300-88G00 RNLS114-528 LRS01370 CST45101 CST45101GS DRS3849 S2018 CST45101ES 25-2216 CST45101AS STR-3024 CST45101OS 8EA737508-001 458631 17196N 160.579.092 111763 STR3026 CST45101RS LRS1370 335788 S114-528 201104 MAV471010 CGB-23849 STR72095 6045101 STRW326 11894 22.1104 S114-528A 20417101BNVideo/Publications
111763 11894 160.579.092 17196N 201104 20417101BN 22.1104 23300-88G00 23300-88G01 25-2216 458631 6045101 88213133 8EA737508-001 AEY1370 CGB-23849 CST45101 CST45101AS CST45101ES CST45101GS CST45101OS CST45101RS DRS3849 JS1104 LRS01370 LRS1370 MAV471010 RNLS114-528 S114-528A S2018 STR-3024 STR72095 STRW326Add Your Number
