Associated Numbers
20R3250 2692757 348-7651 8200528 8201093 STR80200 UD14975S UNIT BOM 141-806Specifications
Kilowatt | 9 kW |
Length (L.1) | 520 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 16 mm |
Mount Hole Diameter (C.2) | 16 mm |
Mount Hole Diameter (C.3) | 16 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | DELCO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | Various Models |
Reference Information
91-01-3948 2692757 8201093 641.004.113.519 8200528 UD14975S 641.004.113.510 STR80200 641.004.113.390 91-01-3948N 20R3250 UD19711S 641.004.113.030 S1169S 641.004.113.392 STD2757 3487651 140-50761 8200098Video/Publications
20R3250 2692757 348-7651 8200528 8201093 STR80200 UD14975S UNIT BOM 141-806Add Your Number
