Associated Numbers
0025900 0461107 0R5207 0R5270 10461107 10461242 10461338 10461341 1113827 1113840 1113853 1113901 1113923 1113928 1113934 1113942 1113949 1113950 1113951 1113959 1113960 1113962 1113967 1113969 1113982 1113990 1113992 1113993 1113998 1114706 1114711 1114712 1114729 1114735 1114740 1114742 1114743 1114759 1114767 1114772 1114774 1114777 1114782 1114793 1114805 1114843 1114845 1114856 1114857 1114858 1114859 1114860 1114861 1114862 1114863 1114864 1114871 1114872 1114905 1114910 1114914 1114917 1114945 1114949 1114953 1114968 1114989 197127 1990297 1990324 1990343 1990414 1990415 1990432 1993704 1993822 1993936 1993945 201-40203 201-40203R 25900 2S0900 2S900 3604233RX 3675120RX 3A1872 3A1872H 3R7356 3T2647 3T2652 3T2660 3T2772 3T4581 3T4582 3T4584 3Y8852 4N3181 4N3347 4N3348 4N3350 5A6494 5A6495 5A6522 5R3155 5R3857 60811 60811D 60811K 60811M 60823 60823P 60823W 60863 60863D 673782C91 690644C92 73130192 7S3622 7T0798 7T0799 7T1082 7T1799 8C3597 8C3647 8C3650 8N2145 91-01-4105 91-01-4105N 9G4337 9G4338 9G4339 9M1662 A47500 AR102770 AR102771 AR36849 AR45036 AR55313 AR55314 D42964 M0017260ME M0017280ME M0017422ME M105R3502SE M105R3503SE M105R3505SE M125R3003SEP MS1-401A MS1-410A MS1-453 R14006 R26137 R43343 R45968 RE38634 RE43047 RE515895 RE61591 S-1139 SE501443 STR20015 TY6610 TY6611 TY6699 TY6721 TY6746 UD12383SSpecifications
| Kilowatt | 6.5 kW |
| Length (L.1) | 511 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Diameter (C.1) | 16.5 mm |
| Mount Hole Diameter (C.2) | 16.5 mm |
| Mount Hole Diameter (C.3) | 16.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 12 qty |
| Pinion at Rest (B) | 47 mm |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | DELCO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 1150 | [301] | 01.1965-12.1970 |
| CASE | 1150 | [401] | 01.1965-12.1972 |
| CASE | 1150 | [6504] | 01.1969-12.1972 |
| CASE | 1400TK | [6504] | 01.1969-12.1972 |
| CASE | W18 | [401] | 01.1971-12.1984 |
| CASE | W18B | [504] | 01.1970-12.1973 |
| CASE | W20 | [401] | 01.1971-12.1979 |
| CASE | W20 | [504] | 01.1970-12.1973 |
| CASE | W24 | [504] | 01.1969-12.1973 |
| CASE | W24B | [504] | 01.1969-12.1976 |
| CASE | W26 | 01.1971-12.1971 | |
| CUMMINS | Engine 9.1 | 01.1983-12.1985 | |
| INTERNATIONAL | 175C | [DT466] | 01.1972-12.1974 |
| INTERNATIONAL | 412 | [DT466] | 01.1971-12.1979 |
| INTERNATIONAL | 412B | [DT466] | 01.1980-12.1987 |
| INTERNATIONAL | 431 | [DVT800] | 01.1980-12.1985 |
| INTERNATIONAL | 433 | [DT466] | 01.1980-12.1985 |
| INTERNATIONAL | 433 | [DVT800] | 01.1980-12.1985 |
| INTERNATIONAL | 433B | [DT466] | 01.1983-12.1985 |
| INTERNATIONAL | 433B | [DVT800] | 01.1983-12.1985 |
| INTERNATIONAL | 433V | [DT466] | 01.1980-12.1985 |
| INTERNATIONAL | 433V | [DVT800] | 01.1980-12.1985 |
| INTERNATIONAL | 442 | [DVT800] | 01.1980-12.1985 |
| INTERNATIONAL | 442B | [DVT800] | 01.1983-12.1985 |
| INTERNATIONAL | 444 | [DT466] | 01.1980-12.1985 |
| INTERNATIONAL | 444 | [DVT800] | 01.1980-12.1985 |
| INTERNATIONAL | 530 | [DT414] | 01.1978-12.1985 |
| INTERNATIONAL | 540 | [DT466B] | 01.1978-12.1985 |
| INTERNATIONAL | 560B | [KT1150C] | 01.1980-12.1985 |
| INTERNATIONAL | H-60E | [D360] | 01.1974-12.1979 |
| INTERNATIONAL | H-65C | [DT414] | 01.1970-12.1979 |
| INTERNATIONAL | H-65E | 01.1979-12.1979 | |
| INTERNATIONAL | H-80B | [DT466] | 01.1974-12.1979 |
| INTERNATIONAL | TD-15C | [D554] | 01.1959-12.1959 |
| INTERNATIONAL | TD-15C | [DT466] | 01.1972-12.1974 |
| INTERNATIONAL | TD-175 | 01.1972-12.1974 | |
| INTERNATIONAL | TD-25C | [DT817] | 01.1972-12.1976 |
| JOHN DEERE | 101G | [V504] | 01.1979-12.1982 |
| JOHN DEERE | 5010 D | 01.1963-12.1965 | |
| JOHN DEERE | 5020 | [6531] | 01.1966-121972 |
| JOHN DEERE | 770 | 01.1975-12.1978 | |
| JOHN DEERE | 770A | 01.1978-12.1983 | |
| JOHN DEERE | 772A | 01.1978-12.1983 | |
| JOHN DEERE | 850 | 01.1978-12.1981 | |
| JOHN DEERE | 855 | 01.1979-12.1981 | |
| JOHN DEERE | 860B D | 01.1977-12.1980 | |
| JOHN DEERE | 862 | [6V71N] | 01.1980-12.1981 |
| JOHN DEERE | 890 | [619] | 01.1978-12.1983 |
| JOHN DEERE | 890A | [619] | 01.1978-12.1983 |
| JOHN DEERE | Engine | [6619] | |
| JOHN DEERE | H-884 | 01.1963-12.1973 | |
| JOHN DEERE | JD700 | [531] | 01.1967-12.1974 |
| JOHN DEERE | JD700A | [531] | 01.1967-12.1974 |
| JOHN DEERE | JD762 | [466] | 01.1975-12.1981 |
| JOHN DEERE | JD762 | [619] | 01.1975-12.1981 |
Reference Information
1113901 0R5207 3A1872 AR55313 AR55314 3675120RX 1113982 5R3857 M125R3003SEP 1114712 1114711 1114953 3A1872H 25900 A47500 9G4337 9G4339 1114793 9G4338 5A6495 73130192 5A6494 M0017260ME 197127 2S900 MS1-410A 1114949 1114706 3Y8852 201-40203R 673782C91 1113853 MAV626040 1114945 M105R3503SE 1990415 1114782 1990414 1113967 3T2660 1113969 M0017280ME 7T1082 1113960 1114774 D42964 1113962 1993936 1113840 1114777 60863D 9M1662 STR2603 2S0900 60823P 1114772 RE38634 7S3622 3T2652 60823W STRF782 TY6746 3T2772 4N3348 MS1-401A 461107 1113959 4N3347 1114805 1993822 1993945 1993704 1113951 1113950 690644C92 R45968 1114767 4N3181 CGB-1139 60823 3604233RX 7T0798 7T0799 3T2647 10461338 1990432 201-40203 1114914 1114759 3T4584 1113827 3T4582 3T4581 1113949 1114917 1114872 4N3350 1113942 1114910 10461341 RE61591 TY6721 1114871 10461107 1990324 R14006 91-01-4105N 8C3650 1113934 1114905 AR36849 1114862 1114740 1114861 1114743 1114864 AR102770 1114742 1114863 AR102771 1114989 M105R3505SE TY6610 TY6611 TY6699 STR20015 1114860 5R3155 R26137 AR45036 91-01-4105 1990297 STRS208 1114859 1113923 1114858 1113928 1114857 MAV626010 1114735 1114856 CGB-1502 10461242 7T1799 3R7356 1990343 0R5270 8C3597 1114968 1114729 R43343 8N2145 RE515895 8C3647 1113993 1113992 1114843 1113998 1114845 RE43047 S-1139 60863 SE501443 UD12383S 5A6522 1113990 MS1-453 S1133 M0017422MEVideo/Publications
0025900 0461107 0R5207 0R5270 10461107 10461242 10461338 10461341 1113827 1113840 1113853 1113901 1113923 1113928 1113934 1113942 1113949 1113950 1113951 1113959 1113960 1113962 1113967 1113969 1113982 1113990 1113992 1113993 1113998 1114706 1114711 1114712 1114729 1114735 1114740 1114742 1114743 1114759 1114767 1114772 1114774 1114777 1114782 1114793 1114805 1114843 1114845 1114856 1114857 1114858 1114859 1114860 1114861 1114862 1114863 1114864 1114871 1114872 1114905 1114910 1114914 1114917 1114945 1114949 1114953 1114968 1114989 197127 1990297 1990324 1990343 1990414 1990415 1990432 1993704 1993822 1993936 1993945 201-40203 201-40203R 2S0900 2S900 3604233RX 3675120RX 3A1872 3A1872H 3R7356 3T2647 3T2652 3T2660 3T2772 3T4581 3T4582 3T4584 3Y8852 4N3181 4N3347 4N3348 4N3350 5A6494 5A6495 5A6522 5R3155 5R3857 60811 60811D 60811K 60811M 60823 60823P 60823W 60863 60863D 673782C91 690644C92 73130192 7S3622 7T0798 7T0799 7T1082 7T1799 8C3597 8C3647 8C3650 8N2145 91-01-4105 91-01-4105N 9G4337 9G4338 9G4339 9M1662 A47500 AR102770 AR102771 AR36849 AR45036 AR55313 AR55314 CGB-1139 CGB-1502 D42964 M0017260ME M0017280ME M0017422ME M105R3503SE M105R3505SE M125R3003SEP MAV626010 MAV626040 MS1-401A MS1-410A MS1-453 R14006 R26137 R43343 R45968 RE38634 RE43047 RE515895 RE61591 S-1139 SE501443 STR20015 STRF782 STRS208 TY6610 TY6611 TY6699 TY6721 TY6746 UD12383S S1133Add Your Number
