Associated Numbers
140-39186 19080035 300516-00020 300516-00020A 6046608 8200589 CST46608 CST46608AS CST46608ES CST46608GS CST46608OS CST46608RS DRS0975N STD9850 UD15213SSpecifications
Kilowatt | 7 kW |
Length (L.1) | 391 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Center - Center (O.2) | 126 mm |
Mount Hole Center - Center (O.3) | 126 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 47.5 mm |
Rotation | CW |
Spigot Diameter (A) | 91.5 mm |
Unit Type | DELCO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DAEWOO | Solar S470LC-V |
Reference Information
CST46608GS 3005160020 CST46608ES 19080035 STD9850 300516-00020A 300516-00020 6046608 CST46608AS DRS0975N 8200589 CST46608OS CST46608 UD15213S 140-39186 CST46608RSVideo/Publications
140-39186 19080035 300516-00020 300516-00020A 6046608 8200589 CST46608 CST46608AS CST46608ES CST46608GS CST46608OS CST46608RS DRS0975N STD9850 UD15213SAdd Your Number
