Associated Numbers
36100-3C040 91-01-4768 DRS0815 PXPSA-014 UD02061SSpecifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 213 mm |
| Mount Hole Center - Center (O.1) | 101 mm |
| Mount Hole Diameter (C.1) | M10x1.75 mm |
| Mount Hole Diameter (C.2) | M10x1.75 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 8 qty |
| No./Teeth (Replaces) | 8 qty |
| Pinion at Rest (B) | 26 mm |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Genesis Coupe 3.8 V6 | [G6DA] | 01.2008- |
Reference Information
UD02061S PXPSA-014 DRS0815 STR2716 36100-3C040 91-01-4768Video/Publications
