Associated Numbers
0986025710 0K30A-18-400 0K326-18-400 112847 114885 201098 201098V 20513071 220118 25-3339 250.001.083 254064 254064D 254166 33165R 36100-2X000 6032110 88212404 8EA012526-731 944280703020 AEY2165 B303-18-400 B303-18-400A CST32110 CST32110AS CST32110ES CST32110GS CST32110OS CST32110RS DRS0047 DRS0047N J5210306 JS1098 KB303-18-400 KB303-18-400A KB308-18-400 KK326-18-400 LRS02165 LRS2165 M003T33281 M35216 M3T33281 MB359-18-400A MC109015 MRS70302 OK326-18-400 S1071(DELCO) S1225M STM1098 STV1098 TM000A18001 UD02053SSpecifications
Kilowatt | 0.85 kW |
Length (L.1) | 184 mm |
Mount Hole Center - Center (O.1) | 78 mm |
Mount Hole Center - Center (O.2) | 110.5 mm |
Mount Hole Center - Center (O.3) | 78 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | M10x1.25 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 8 qty |
No./Teeth (Replaces) | 8 qty |
Pinion at Rest (B) | 13 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KIA | Carens 1.6 | [GA6D] | 07.2002- |
KIA | Pride 1.3 i | [B3] | 01.1990- |
KIA | Rio 1.5 | [A5D] | 09.2002-02.2005 |
KIA | Shuma 1.6 | [GA6D] | 05.2001-05.2004 |
KIA | Spectra 1.6 | 01.2001-12.2004 |
Reference Information
220118 3M162 M003T33281 6032110 KB303-18-400A 000986025710 112847 KK326-18-400 B303-18-400 B303-18-400A 003-M162 254166 36100-2X000 CST32110AS CST32110ES 8EA012526-731 STR2035 254064 JS1098 CST32110RS DRS0047N 986025710 M3T33281 J5210306 20513071 201098 0K326-18-400 201098V J5210302 DRS0047 LRS2165 254064D CST32110 UD02053S 88212404 AEY2165 M35216 9.44281E+11 KB303-18-400 114885 5032082 250.001.083 KB308-18-400 MTM162 OK326-18-400 CST32110OS 336251 MRS70302 S1225M STM1098 STV1098 CST32110GS 0K30A-18-400 OK30A-18-400 MC109015 25-3339 S1071(DELCO) RK30A18400U 33165R OK30A18400 TM000A18001 S12HY0434A2 MB359-18-400A LRS02165Video/Publications
003-M162 0986025710 0K30A-18-400 0K326-18-400 112847 114885 201098 201098V 20513071 220118 25-3339 250.001.083 254064 254064D 254166 33165R 36100-2X000 3M162 6032110 88212404 8EA012526-731 944280703020 AEY2165 B303-18-400 B303-18-400A CST32110 CST32110AS CST32110ES CST32110GS CST32110OS CST32110RS DRS0047 DRS0047N J5210302 J5210306 JS1098 KB303-18-400 KB303-18-400A KB308-18-400 KK326-18-400 LRS02165 LRS2165 M003T33281 M35216 M3T33281 MB359-18-400A MC109015 MRS70302 MTM162 OK326-18-400 S1071(DELCO) S1225M STM1098 STV1098 TM000A18001 UD02053SAdd Your Number
