Associated Numbers
115758 1209422 25-4314 250.508.082 254849 36100-2G000 36100-2G200 36100-2G300 6032123 6975N 6975R 8000285 8000357 91-01-4740 9790 CST32123 CST32123AS CST32123ES CST32123GS CST32123OS CST32123RS LRS02641 LRS2641 S-1513 S1075R STR80178 UD02058SSpecifications
Kilowatt | 1.2 kW |
Length (L.1) | 198 mm |
Mount Hole Center - Center (O.1) | 94 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | ix35 2.0 | [G4KD] | 01.2010- |
HYUNDAI | ix35 2.4 4x4 | [G4KE] | 01.2010-12.2013 |
HYUNDAI | Santa Fe 2.4 | [G4KE] | 01.2010- |
HYUNDAI | Santa Fe 2.4 4x4 | [G4KE] | 01.2010- |
HYUNDAI | Sonata 2.4 | [G4KC] | 01.2009- |
KIA | Sorento 2.4 CVVT | [G4KE] | 01.2009- |
KIA | Sorento 2.4 CVVT 4x4 | [G4KE] | 01.2009- |
KIA | Sportage 2.0 CVVT | [G4KD] | 01.2010- |
KIA | Sportage 2.0 CVVT AWD | [G4KD] | 01.2010- |
Reference Information
6975R CST32123AS 3610025020 36100-2G250 115758 STR80178 CST32123RS 36100-2G400 25-4314 254849 UD02058S 8000357 6975N CST32123 6032123 1209422 36100-2G000 S1075R 36100-2G300 36100-2G200 9790 LRS02641 S-1513 91-01-4740 CST32123OS 8000285 CST32123ES 6974N CST32123GS LRS2641 STR2093 250.508.082Video/Publications
115758 1209422 25-4314 250.508.082 254849 36100-2G000 36100-2G200 36100-2G300 6032123 6975N 6975R 8000285 8000357 91-01-4740 9790 CST32123 CST32123AS CST32123ES CST32123GS CST32123OS CST32123RS LRS02641 LRS2641 S-1513 S1075R STR80178 UD02058SAdd Your Number
