Associated Numbers
0-23000-2070 10106 10461287 10461483 1113284 112668 201-28125 20409541BN 3575130RX 3675130RX 50-8436 50-8436-1 6060145 6600 6600N 8718R CST60145AS TS-1648 UD02205SSpecifications
Kilowatt | 2.8 kW |
Length (L.1) | 338 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HOUGH | Various Models | 01.1989- | |
KOMATSU | Various Models | 01.1988- |
Reference Information
112668 UD02205S 20409541BN STR80071 0-23000-2070 140-28148 CST60145AS 10461483 MAV621450A 10461287 540.507.103.038 6060145 STR2000 0-61000-0280 540.507.103.030 91-01-4414 S1065 STD2668 6600N 91-01-4414NVideo/Publications
0-23000-2070 10106 10461287 10461483 1113284 112668 201-28125 20409541BN 3575130RX 3675130RX 50-8436 50-8436-1 6060145 6600 6600N 8718R CST60145AS MAV123370 TS-1648 UD02205S S1065Add Your Number
