Associated Numbers
10479604 140-28124 20409411BN 254218 35258940 50-8419 6060114 6590 6590N CST60114 CST60114AS CST60114ES CST60114GS CST60114OS CST60114RS TS-1620 UD02197SSpecifications
Kilowatt | 2.8 kW |
Length (L.1) | 335 mm |
Mount Hole Center - Center (O.1) | 89 mm |
Mount Hole Center - Center (O.2) | 89 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 88.8 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CLARK | Various Models | 01.1968- |
Reference Information
10479604 STRF438 CST60114AS STR2683 6060114 6590N CST60114ES 140-28124 20409411BN CST60114 CST60114GS MAV621140 6590 TS-1620 339801 50-8419 CST60114OS CST60114RS 254218 UD02197S 35258940Video/Publications
10479604 140-28124 20409411BN 254218 35258940 50-8419 6060114 6590 6590N CST60114 CST60114AS CST60114ES CST60114GS CST60114OS CST60114RS MAV621140 STRF438 TS-1620 UD02197SAdd Your Number
