Associated Numbers
10479107 114325 19026031 1993756 1993879 20409131OE 255239P 3965281 6060131 6809N 8200023 8200077 8300024 CST60131GS M105R2510SE M105R2511SE STR80101 UD01313SSpecifications
Kilowatt | 4.6 kW |
Length (L.1) | 407 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | Engine 6.7 | [QSB] | |
CUMMINS | Engine 8.3 | [QSC] |
Reference Information
255239P M105R2511SE 10479107 M105R2510SE STRL869 20409131OE 1993756 1993879 8300024 114325 MAV621120 STR80101 6809N UD01313S 6060131 CST60131GS 3965281 STR2187 8200077 8200023 19026031Video/Publications
10479107 114325 19026031 1993756 1993879 20409131OE 255239P 3965281 6060131 6809N 8200023 8200077 8300024 CST60131GS M105R2510SE M105R2511SE MAV621120 STR80101 STRL869 UD01313SAdd Your Number
