Associated Numbers
6834N 8200007 8300022 M105R2517SE STD0007 STR80174 UD01283SSpecifications
Kilowatt | 4.6 kW |
Length (L.1) | 408 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
Mount Hole Diameter (C.3) | 13.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
No./Teeth (Replaces) | 10 qty |
Pinion at Rest (B) | 47.5 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
INTERNATIONAL | 1400 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 1600 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 1700 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 1800 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 1900 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 2000 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 3000 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 4000 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 5000 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 8000 7.6 | [DT-466] | 01.1994-12.2003 |
INTERNATIONAL | 9000 7.6 | [DT-466] | 01.1994-12.2003 |
Reference Information
STR80174 8200007 6834N UD01283S STR2110 8300022 M105R2517SE STD0007Video/Publications
6834N 8200007 8300022 M105R2517SE STD0007 STR80174 UD01283SAdd Your Number
