Associated Numbers
10465013 10465053 10465054 10465168 1113266 1113267 1113269 1113270 1113295 1113296 112341 19136221 20409111BN 20409111OE 22.0970 25-2288 33935 6060111 60970 6468N 6469N 88213353 CST60111 CST60111AS CST60111ES CST60111GS CST60111OS CST60111RS DRZ5176 LRS01401 STR80015 US970
57-030 dxs9128
SND296 70-0253
ARROWHEAD 410-12762, SNK0002
BOSCH SR8574N, SR8574X
DELCO 10465014, 10465054, 10465168, 10465170, 1109219, 1109563, 1113267, 1113270, 1113295, 1113296, 1113589, 1113590, 1998401, 1998442, 323-406, 323-407, 323-446, 323-447
HITACHI S1581
J&N ELECTRICAL PRODUCTS 410-12040
JANNCO 410-12037R, 410-12040R, 410-12762N
LESTER 6343, 6347, 6469
LUCAS ELECTRIC S2770, S2774
NIKKO 0-23000-1581, 0-23000-1588
AC DELCO TOOLS 323-299, 323-381, 323-407, 323-447, 336-1912
ARROWHEAD 410-12762, NK0-23000-1588, SNK0002
BOSCH SR577X, SR8574N, SR8574X
DELCO 10465014, 10465054, 10465168, 10465170, 1109219, 1109563, 1113267, 1113270, 1113295, 1113296, 1113589, 1113590, 19136221, 1998401, 1998442, 323-406, 323-407, 323-446, 323-447
HITACHI S1581
J&N ELECTRICAL PRODUCTS 410-12037R, 410-12040, 410-12040R, 410-12762
JANNCO 410-12037R, 410-12040R, 410-12762N
LESTER 3764, 6343, 6347, 6469
LUCAS ELECTRIC LRS01359, S2770, S2774
NIKKO 0-23000-1581, 0-23000-1588, 0-61000-0080
AC DELCO TOOLS 323-299, 323-381, 323-407, 323-447, 336-1912
ARROWHEAD NK0-23000-1588, SNK0001, SNK0002
BOSCH SR577X, SR615X, SR8574N, SR8574X
DELCO10465013, 10465014, 10465053, 10465054, 10465168, 10497165, 1109219, 1109563, 1113266, 1113267, 1113269, 1113270, 1113295, 1113296, 1113589, 1113590, 19136221, 1998401, 1998442, 323-299, 323-381, 323-407, 323-446, 323-447, 336-1912
J&N ELECTRICAL PRODUCTS 410-12037R, 410-12040, 410-12040R, 410-12132
LESTER 3764, 6468, 6469
LUCAS ELECTRIC LRS01359
NIKKO 02-23-1000, 0-23000-1571, 0-23000-1581, 0-23000-1588, 0-61000-0080
0610000080
0986CN1431 Bosch ruil
0986UN1431 Bosch ruil
0986UR1431 Bosch ruil
103970 FARC
10465013 Remy
10465014 Remy
10465053 Remy
10465054 Remy show
10465130 Delco
10465168 Remy
10497165 Delco
111256 Cargo
1113267 Remy show
1113270 Remy show
1113296 Remy show
1113296SEL +line
19136221 Remy
1998401 Remy
252183 Elstock
252288 Elstock
28MT Remy
33935 EAI
6469 Lester
830011102 PSH
830545102 PSH
91013927 Wilson
A90910 ATL
DRL431 Remy
DRZ5176 Remy
DS52
F042003092 Bosch
F042S03092 Bosch
LRS01401 Lucas
SDR1041 Arrowhead
SR8574N Bosch (USA)
SR8574X Bosch (USA)
STR7055 Unipoint show
US970 HC
0230001571 Nikko
0230001581 Nikko
10465013 Remy
10465053 Remy
10465054 Remy show
10465168 Remy
10465296 Remy
111256 Cargo
1113266 Remy
1113267 Remy show
1113269 Remy show
1113269SEL +line
1113295 Remy show
19136220 Remy
28MT Remy
6468 Lester
830011102 PSH
830546102 PSH
91013926 Wilson
DRL497 Remy
DS52
LNG3512F Chevrolet
SDR1040 Arrowhead
SDR1041 Arrowhead
US970 HC
WAI ECO Reman 6469R
WAI New 6469N
WAI Old 2-1581-DR, 23488A, 50-105-9, 50-8402, 50-8402-1, 50-8402-2
ACE Electric CM8001
ACE Zorkos CM6469N
Alltech 104-6469
American Power Systems APS6469
Armature G Roy 6469
Arrow Automotive Industries 35-1938
Ashdown Ingram DXS9128
Atelier Dynamo S6469
Auto Electric Suppliers 6469N, 6469N-7
Beck Arnley New 189-6138
Beck Arnley Remanufactured 187-6138
Bepco 80-6469
Bepco Old 3471X
Bosch Remanufactured SR8574X
Bowers BSO7096
Canadian Tire 0195757, 0198610, 0198744
Champion Parts Rebuilders 7672, 7673
CPC 6469N, 6469S
CPI KIT
Delco 10465014, 10465054, 10465168, 1113267, 1113270, 1113296, 19136221
Delphi SX1104
DNS SS8401, SS8402
DuBois 681-296, 681296, STR7068
EGI S-6469
Elmar 250-4402
Elpar Industries 011103632
Excel 2012
GM 10465014, 10465054
Just Parts NK2-0002N
Knight Rebuilding S8201
Lester 6469
Lucas Electrical Europe LRS01401
Lucas Elektrik LES0197
Lucas Remanufactured S2774
Machinery Components GMS-296
Metron 6469
Metron USA D-6469S
MFR Series - Family Type 28MT
Minnpar 57-2676
Minnpar Old 6882676
Mondial 70-429-30
Mondial New 70-429-30N
Nastra 6469
Nastra New 886469
Nastra Velocity E6469
New Generation 604720
New Tech N6469
Our Part Number 6469N, 6469R
Part # 6469
PASCO S-500923
Power Select 6469N, 6469R
Powerite Automotive 6469
Precision Parts & Remanufacturing GMS447
PTS 281210
Quality Rebuilders 5519
Raw Power 6469N, 6469R
Rayloc 46-5092, 465092
Rayloc New 4N5092
RCP 23487A, 23488A, ST-6468, ST-6469, ST-70550
Reliance 3750
Road Warrior 6469N, 6469R
Rotex 6469
Stratoline 3471X, 80-6469
Stratoline (Old) 3471X
Suncoast 6469
Suncoast New 30-6469
Techno CVC IND-2313266, IND-2313267
TSA 6469N
UCP New 6469N
UCP Remanufactured 6469
Ultima Select 396100
Unit Parts 8401S, 8402S
USA Industries 6472
Wood Auto Supplies STR7055
Zorko 6468N, 6469
Specifications
| Kilowatt | 2.5 kW |
| Length (L.1) | 335 mm |
| Mount Hole Center - Center (O.1) | 85 mm |
| Mount Hole Diameter (C.1) | 10 mm |
| Mount Hole Diameter (C.2) | 10 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| No./Teeth (Replaces) | 10 qty |
| Pinion at Rest (B) | 8 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | C1500 6.5 | 01.1994-12.1995 | |
| CHEVROLET | C1500 6.5 Turbo | 01.1994-12.1998 | |
| CHEVROLET | C2500 6.2 | 01.1988-12.1995 | |
| CHEVROLET | C2500 6.5 | 01.1994-12.1995 | |
| CHEVROLET | C2500 6.5 Turbo | 01.1992-12.2000 | |
| CHEVROLET | C3500 6.5 Turbo | 01.1992-12.2000 | |
| CHEVROLET | G20 6.5 | 01.1994-12.1995 | |
| CHEVROLET | G20 6.5 Sportvan | 01.1994-12.1995 | |
| CHEVROLET | G20 6.5 Turbo | 01.1996-12.1997 | |
| CHEVROLET | G20 6.5 Turbo Express | 01.1997- | |
| CHEVROLET | G30 6.2 | 01.1992-12.1992 | |
| CHEVROLET | G30 6.5 | 01.1994- | |
| CHEVROLET | G30 6.5 Sportvan | 01.1994- | |
| CHEVROLET | G30 6.5 Turbo | 01.1996-12.1997 | |
| CHEVROLET | G30 6.5 Turbo Express | 01.1996-12.1997 | |
| CHEVROLET | K1500 6.5 | 01.1994- | |
| CHEVROLET | K1500 6.5 Turbo | 01.1994-12.1998 | |
| CHEVROLET | K2500 6.2 | 01.1989-12.1993 | |
| CHEVROLET | K2500 6.5 | 01.1994- | |
| CHEVROLET | K2500 6.5 Turbo | 01.1992-12.2000 | |
| CHEVROLET | K3500 6.5 Turbo | 01.1992-12.2000 | |
| CHEVROLET | P30 6.5 | 01.1994-12.1997 | |
| CHEVROLET | P30 6.5 Turbo | 01.1994-12.1997 | |
| CHEVROLET | R3500 6.2 | 01.1989-12.1991 | |
| CHEVROLET | Tahoe 6.5 Turbo | 01.1995-12.1998 | |
| CHEVROLET | V3500 6.2 | 01.1989- | |
| GMC | C1500 6.2 SieRa | 01.1989-12.1993 | |
| GMC | C1500 6.2 SieRa XC | 01.1989-12.1993 | |
| GMC | C1500 6.5 SieRa | 01.1994-12.1995 | |
| GMC | C1500 6.5 SieRa XC | 01.1994-12.1995 | |
| GMC | C1500 6.5 Turbo SieRa | 01.1994-12.1997 | |
| GMC | C1500 6.5 Turbo SieRa XC | 01.1994-12.1996 | |
| GMC | C2500 6.2 SieRa | 01.1989-12.1993 | |
| GMC | C2500 6.2 SieRa XC | 01.1989-12.1993 | |
| GMC | C2500 6.5 SieRa | 01.1994-12.1995 | |
| GMC | C2500 6.5 SieRa XC | 01.1994-12.1995 | |
| GMC | C2500 6.5 Turbo SieRa | 01.1992-12.1998 | |
| GMC | C2500 6.5 Turbo SieRa XC | 01.1993-12.1998 | |
| GMC | C3500 6.2 SieRa | 01.1989-12.1993 | |
| GMC | C3500 6.2 SieRa XC | 01.1989-12.1993 | |
| GMC | C3500 6.5 Turbo SieRa | 01.1992-12.1997 | |
| GMC | C3500 6.5 Turbo SieRa XC | 01.1992-12.1997 | |
| GMC | G25/G2500 6.2 Rally | 01.1991-12.1993 | |
| GMC | G25/G2500 6.2 Vandura | 01.1991-12.1993 | |
| GMC | G25/G2500 6.5 Rally | 01.1994-12.1995 | |
| GMC | G25/G2500 6.5 Turbo Cargo | 01.1997- | |
| GMC | G25/G2500 6.5 Turbo Savana | 01.1996-12.1996 | |
| GMC | G25/G2500 6.5 Turbo XT | 01.1997- | |
| GMC | G25/G2500 6.5 Vandura | 01.1994-12.1995 | |
| GMC | G35/G3500 6.2 | 01.1991-12.1993 | |
| GMC | G35/G3500 6.2 Rally | 01.1991-12.1993 | |
| GMC | G35/G3500 6.2 Vandura | 01.1991-12.1993 | |
| GMC | G35/G3500 6.5 | 01.1994-12.1996 | |
| GMC | G35/G3500 6.5 Rally | 01.1994-12.1996 | |
| GMC | G35/G3500 6.5 Turbo | 01.1996-12.1996 | |
| GMC | G35/G3500 6.5 Turbo Savana | 01.1996-12.1997 | |
| GMC | G35/G3500 6.5 Vandura | 01.1994-12.1996 | |
| GMC | Jimmy 6.2 | 01.1991-12.1991 | |
| GMC | K1500 6.2 SieRa | 01.1989-12.1993 | |
| GMC | K1500 6.2 SieRa XC | 01.1989-12.1993 | |
| GMC | K1500 6.5 SieRa | 01.1994-12.1995 | |
| GMC | K1500 6.5 SieRa XC | 01.1994-12.1995 | |
| GMC | K1500 6.5 Turbo SieRa | 01.1994-12.1998 | |
| GMC | K1500 6.5 Turbo SieRa XC | 01.1994-12.1998 | |
| GMC | K2500 6.2 SieRa | 01.1989-12.1993 | |
| GMC | K2500 6.2 SieRa XC | 01.1989-12.1993 | |
| GMC | K2500 6.5 SieRa | 01.1994-12.1994 | |
| GMC | K2500 6.5 Turbo SieRa | 01.1992-12.1994 | |
| GMC | K2500 6.5 Turbo SieRa XC | 01.1992-12.1994 |
Reference Information
STR2685 339120 88213353 22.097 1113267 10465053 1113266 10465054 CST60111 1113269 STR8843 10465013 STR80015 STRW293 LRS01401 CST60111GS STRS798 6060111 60970 CST60111OS 20409111BN 33935 LRS1401 6468N S1005 US970 DRZ5176 19136221 CST60111AS 20409111OE MAV621110 CST60111ES 10465168 1113270 25-2288 1113296 1113295 112341 CST60111RS 6469NVideo/Publications
10465013 10465053 10465054 10465168 1113266 1113267 1113269 1113270 1113295 1113296 112341 19136221 20409111BN 20409111OE 22.0970 25-2288 33935 6060111 60970 6468N 6469N 88213353 CST60111 CST60111AS CST60111ES CST60111GS CST60111OS CST60111RS DRZ5176 LRS01401 LRS1401 MAV621110 STR80015 STRS798 STRW293 US970 S1005Add Your Number
