Associated Numbers
0001364300 UD16586S 05710935 0001364101 112651 CST10695AS 8676 DRS2700 DS3810 260-64201 33464 45-0249 IS0030 11.132.342 AZJ3481 11.130.672 AZJ3221 01179595 1179595 1164376 STB2651 LRS01813 MS174 72735802 88213615 561.001.113 20401596BN 120-30110 182-30199 6010695.0 5278775 5636102 D11E149 91-15-6929 STR50285 STR22080 MAHMS174 TS-6054Specifications
Kilowatt | 4.8 kW |
Length (L.1) | 358 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KHD | Engine | [F4L413R] | 01.1973-12.1975 |
KHD | Engine | [F5L413R] | 01.1973-12.1975 |
KHD | Engine | [F6L413R] | 01.1973- |
KHD | Engine 9.6 | [BF6L413FR] | 01.1988- |
Reference Information
91-15-6929 STR7839 11.132.342 AZJ0602 MS174 MAV126950 45-0249 5636102 6010695 120-30110 0001364101 1179595 0001364300 STR22080 MS TS-6054 UD16586S 182-30199 DRS2700 5710935 STR50285 CST10695AS 1364300 LRS01813 1364101 AZJ3221 88213615 S0795S IS0030 20401596BN MAHMS174 STR1112 72735802 8676 5278775 174 11.130.672 STB2651 STRL165 612 561.001.113 DS3810 D11E149 112651 MAV126110 33464 1164376 260-64201 AZJ3481 LRS1813Video/Publications
0001364101 0001364300 01179595 05710935 11.130.672 11.132.342 112651 1164376 120-30110 182-30199 20401596BN 260-64201 33464 45-0249 5278775 561.001.113 5636102 6010695.0 72735802 8676 88213615 91-15-6929 AZJ0602 AZJ3221 AZJ3481 CST10695AS D11E149 DRS2700 DS3810 IS0030 LRS01813 LRS1813 MAHMS174 MAV126110 MAV126950 MS 174 MS 612 STB2651 STR22080 STR50285 STRL165 TS-6054 UD16586SAdd Your Number
