Associated Numbers
0001108150 0001108177 0001108178 11874 1202024 130.520.092 17720N 17720R 20401623 25-2105 3866 6010326 8EA737182-001 90379385 90487546 90566072 91-15-7024 CS982 CST10326 CST10326AS CST10326ES CST10326GS CST10326OS CST10326RS LRT00140 S-6163 STB0982 STM1104 STR50129 UD00859SSpecifications
Kilowatt | 1.4 kW |
Length (L.1) | 229 mm |
Mount Hole Center - Center (O.1) | 117 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 19 mm |
Rotation | CW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Omega B 2.5 V6 | [X25XE] | 03.1994-09.2000 |
OPEL | Omega B 2.6 V6 | [Y26SE] | 09.2000-07.2003 |
OPEL | Omega B 3.0 V6 | [X30XE] | 04.1994-02.2001 |
OPEL | Omega B 3.2 V6 | [Y32SE] | 02.2001-07.2003 |
VAUXHALL | Omega 2.5 V6 | [X25XE] | 03.1994-09.2000 |
VAUXHALL | Omega 3.0 V6 | [X30XE] | 04.1994-07.2000 |
VAUXHALL | Omega 3.0 V6 | [X30XE] | 07.1994-07.2000 |
Reference Information
90487546 1108177 0001108178 0001108177 1108178 130.520.092 S-6163 1108150 0001108150 CST10326OS UD00859S CS982 MAV6390 S0768S 90566072 17720R CST10326 STM1104 17720N 93184539 90379385 CST10326ES CST10326GS CST10326AS 1202169 1202024 91-15-7024 STB0982 6202082 MAV123260 25-2105 8EA737182-001 LRT00140 STR50129 11874 6010326 3866 20401623 STRF376 CST10326RSVideo/Publications
0001108150 0001108177 0001108178 11874 1202024 130.520.092 17720N 17720R 20401623 25-2105 3866 6010326 8EA737182-001 90379385 90487546 90566072 91-15-7024 CS982 CST10326 CST10326AS CST10326ES CST10326GS CST10326OS CST10326RS LRT00140 MAV123260 MAV6390 S-6163 S0768S STB0982 STM1104 STR50129 STRF376 UD00859SAdd Your Number
